Peavey 6505 Plus 120W Guitar Amp Head (Discontinued)

Peavey 6505 Plus 120W Guitar Amp Head (Discontinued)

Name: Peavey 6505 Plus 120W Guitar Amp Head (Discontinued)
Brand: Peavey
SKU: PEAVEY-00575680
Price: 1299.99 USD
Availability: OutOfStock

Write a Review

Part #:

00575680

Model #:

6505 Plus

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Named in celebration of Peavey's first 40 years, the 6505 Plus is the undisputed go-to Peavey amplifier head for scores of rock, hardcore and metal bands for their raw tone, relentless power and road-proven reliability.

Description

The 6505 Plus is still the unquestionable choice for an ever-expanding list of endorsers. The 6505 Plus features six 12AX7 preamp tubes and four 6L6GC power amp tubes, with presence and resonance controls and three-band EQ for taming their notorious tone. The 6505 Plus is the undisputed go-to guitar amp series for scores of rock and metal bands due to their raw tone, relentless power and road-proven reliability. The 6505 Plus is still the unquestionable choice for an ever-expanding list of endorsers.

Features

Six 12AX7 preamp and four 6L6GC power amp tubes.
Footswitchable Lead/Rhythm channel select.
Three-band EQ on each channel.
Resonance and Presence controls on each channel.
Pre Gain and Post Gain on each channel.
Footswitchable Crunch boost on Rhythm channel.
Bright switch on Rhythm channel.
Preamp output.
Effects loop.
Bias test point.
Footswitch included.
120 watts RMS into 16, 8 or 4 ohm.

Specifications

Power Amplification
Rated Power and Load	120 W RMS into 16, 8, or 4 ohms
Power @ Clipping	(Typically @ 5% THD, 1 kHz, 120 V AC line) 130 W RMS into 16, 8, or 4 ohms
Frequency Response	+0, -3 dB, 50 Hz to 20 kHz @ 100 WRMS into 8 ohms
Hum and Noise	Greater than 75 dB below rated power
Power AMP EQ	Active Presence: +10 dB @ 2 kHz Active Resonance: +10 dB @ cabinetresonant frequency
Power Consumption (Domestic)	400 watts 50/60 Hz, 120 V AC(Domestic)
Tube Complement	6-12AX7 preamp tubes(1 for clean/crunch, 3 for Lead, 1 for EFX and 1 phase splitter 4-6L6GC
Preamp Input
Impedance	Very high Z, 470K ohms
Lead Channel (with channel select in)Nominal Input Level	-60 dBV,1 mV RMS
Minimum Input Level	-76 dBV,.15 mV RMS
Clean Channel (with channel select out)Nominal Input Level	-30 dBV,30 mV RMS
Minimum Input Level	-34 dBV,20 mV RMS
Maximum Input Level	0 dBV,1.0 V RMS(Subtract 24 dB with Crunch switch in.)
Effects Send
Load Impedance	47 k ohms or greater
Nominal Output	-10 dBV, 300 mV RMS
Effects Return
Impedance	Very High Z, 470 k ohms
Designed Level	-10 dBV, 300 mV RMS
Preamp Out
Load Impedance	47 k ohms or greater
Nominal Output	+10 dBV, 3 V RMS
Remote Footswitch	Special 3-button unit with LED indicators
System Hum and Noise@Nominal Level (clean channel)	(20 Hz to 20 kHz unweighted) Greater than 63 dB below rated power
General
Dimensions (W x H x D)	13.25" (336.55 mm) x 28.75" (730.25 mm) x 14" (355.6 mm)
Weight Unpacked	48.30 lbs (21.908 kg)
Weight Packed	57.00 lbs (25.855 kg)
