Peavey Classic 50 212 Guitar Amplifier (Discontinued)

Description

Details

With its responsive gain structure and warm/punch double-team of 12AX7 and EL84 tubes, Classic(R) Series guitar amps are revered by gritty blues benders, chicken pickin’ country cats and nouveau-Stones rockers alike. These amps are available in vintage tweed with Blue Marvel® speakers and knobs straight out of the rock ‘n’ roll revolution.

Features

Features

50 watts (rms) into 16 or 8 ohms.
Fan cooled.
Four EL84s and three 12AX7s.
2-channel preamp.
Normal and bright inputs.
Pre- and post-gain controls on lead channel.
Active presence control.
3-band passive EQ (bass, middle, treble).
Master volume control.
Standby switch.
Reverb level control.
Effects loop.
External speaker capability.
Footswitch selectable channel switching and reverb.
Classic tweed covering.
Chrome-plated chassis.
Cover available.

Specification

Power Amplifier Section	Four 6BQ5/EL84’s with 12AX7 driver
Rated Power & Load	50 W RMS into 16 or 8 ohms
Power @ Clipping (Typically)	(5% THD, 1 kHz, 120 V AC line) 50 W RMS into 16 or 8 ohms
Frequency Response	+0, -2 dB, 50 Hz to 15 kHz, @ 40 W RMS into 16 ohms
Hum & Noise	No greater than 80 dB below rated power
Power Consumption	200 watts, 50/60 Hz, 120 VAC (Domestic)
Nominal level	Input Gain @ 6
Minimum level	Input Gain @ 12
Preamp Normal Input	Impedance: Very high Z, 470 K ohms
Lead Channel (Post Gain @ 10)	Nominal Input Level: -40 dBV, 10 mV RMS Minimum Input Level: -70 dBV, 0.3 mV RMS
Nominal Input Level	-17 dBV, 140 mV RMS
Minimum Input Level	-28 dBV, 40 mV RMS
Maximum Input Level	0 dBV, 1.0 V RMS
Preamp Bright Input	Impedance: Very high Z, 470 K ohms +12 dB boost @ 2 kHz
Equalization (Lead and Normal Channels)	Custom bass, middle, and treble passive-type EQ
Effects Send	Load Impedance: 1 K ohm or greater Nominal Output Level: -6 dBV, 0.5 V RMS
Effects Return	Impedance: High Z, 2 M ohms Designed Input Level: -6 dBV, 0.5 V RMS
External Footswitch Function	Reverb Defeat (when reverb control is raised) Normal/Lead Channel Select (when Lead activated)
Dimensions (W x H x D) (Packed)	12.62" (320.55 mm) x 27.62" (701.55 mm) x 21.5" (546.1 mm)
Weight Unpacked	59.60 lbs (27.034 kg)
Weight Packed	69.00 lbs (31.298 kg)
