Peavey Classic 50 410 Guitar Amplifier (Discontinued)

Description

Details

Originally launched in 1991, these versatile all-tube amps retain their distinctive sound and circuitry but now feature an updated chassis design. With three 12AX7s up front and four EL84 power amp tubes plus normal and bright inputs, 3-band passive EQ, and presence control, it's all the classic tone you seek and all the gigging versatility you need.

Features

Features

Normal and bright inputs
Four EL84s and three 12AX7s
3-band passive EQ
Presence control
Normal and lead volume
Lead pre- and post-gain
Chrome-plated chassis
Four 10 inch Blue Marvel® speakers
Footswitch for channel switching and reverb (included)

Specification

Power Amplifier Section	Four 6BQ5/EL84’s with 12AX7 driver
Rated Power & Load	50 W RMS into 16 or 8 ohms
Power @ Clipping (Typically)	(5% THD, 1 kHz, 120 V AC line) 50 W RMS into 16 or 8 ohms
Frequency Response	+0, -2 dB, 50 Hz to 15 kHz, @ 40 W RMS into 16 ohms
Hum & Noise	No greater than 80 dB below rated power
Power Consumption	200 watts, 50/60 Hz, 120 VAC (Domestic)
Preamp Section	Specifications
Nominal level is with Input Gain	@ 6
Minimum level is with Input Gain	@ 12
Preamp Normal Input	Impedance: Very high Z, 470 K ohms
Lead Channel (Post Gain @ 10)	Nominal Input Level: -40 dBV, 10 mV RMS Minimum Input Level: -70 dBV, 0.3 mV RMS
Nominal Input Level	-17 dBV, 140 mV RMS
Minimum Input Level	-28 dBV, 40 mV RMS
Maximum Input Level	0 dBV, 1.0 V RMS
Preamp Bright Input	Impedance: Very high Z, 470 K ohms +12 dB boost @ 2 kHz
Equalization (Lead and Normal Channels)	Custom bass, middle, and treble passive-type EQ
Effects Send	Load Impedance: 1 K ohm or greater Nominal Output Level: -6 dBV, 0.5 V RMS
Effects Return	Impedance: High Z, 2 M ohms Designed Input Level: -6 dBV, 0.5 V RMS
External Footswitch Function	Reverb Defeat (when reverb control is raised) Normal/Lead Channel Select (when Lead activated)
Dimensions (W x H x D) (Packed)	14.87" x 28" x 27.75" (37.7698 cm x 71.12 cm x 70.485 cm)
Weight Unpacked	61 lbs (27.669 kg)
Weight Packed	71 lbs (32.205 kg)
