The QSC AC-C4T 4" full range ceiling mount loudspeaker is designed for applications where voice reinforced coverage is of primary concern, while still providing improved musicality often not seen in typical BGM class products.

Description

QSC AC-C4T 4-inch 2-Way In-Ceiling Loudspeaker

The QSC AC-C4T is a 4" full range ceiling mount loudspeaker. It is an AcousticCoverage loudspeaker which is designed to offer integrators a cost effective solution for applications where voice reinforced coverage is of primary concern, while providing improved musicality often not seen in typical BGM class products. Applications for AccousticCoverage speakers include wide area paging systems, background music, office buildings, healthcare facilities, concourses, transportation terminals and more.

The AC-C4T provides exceptional clarity through the critical voice range. It has a ported baffle for increased low frequency extension down to 70 Hz and low saturation 70/100V transformers with 8 ohm bypass. Its advanced voicing filter sets use QSC Intrinsic Correction which is available through either Q-Sys processing or CXD amplifier platforms.

Features

High quality 4” full-range transducer
Ported baffle for increased low frequency extension
Low saturation 70/100V transformers with 8 ohm bypass
4 pole Euroblock connector eases system wiring
Advanced voicing filter sets using QSC Intrinsic Correction™
Comes in white with UV inhibitors to match complimenting QSC product families

Specifications

Effective Frequency Range	70 – 16 kHz
Rated Noise Power / Voltage	16 watts / 11.3 volts (rms)
Broad-Band Sensitivity	89 dB SPL
Coverage Angle (-6 dB)	140° (500 Hz - 5 kHz)
Maximum Continuous SPL	101 dB
Maximum Peak SPL	107 dB
Rated Impedance	8 ohms
Transformer Taps	70V: 16, 8, 4, 2, 1 watts and 8 ohm bypass 100V: 16, 8, 4, 2, watts and 8 ohm bypass
Transducer	4" Polypropylene cone with butyl rubber surround
Input Connector Type	Euroblock connector with parallel output terminals
Baffle Material	Painted ABS polymer
Grille Material	Powder coated steel
Back Can Material	Galvanized steel
Testing	Listed UL1480, UL2043 safe for use in air handling space
Included Accessories	Rails & C-ring for ceiling tile installation
Ceiling Capture Thickness	0.25" - 1.5" (6.35 mm - 38.1 mm)
Cut-out Dimensions	7.31" (186 mm)
Product Dimensions	8.4" x 7.9" (214 mm x 201 mm)
Shipping Dimensions	10.75" x 24" x 10.5" (273 mm x 610 mm x 267 mm)
Net Weight	4.9 lbs (2.22 kg)
Shipping Weight (Pair)	15.1 lbs (6.86 kg)
