QSC GP118-sw 18" Passive Subwoofer (Discontinued)

The QSC GP118-sw is a powerful subwoofer that offers plenty of “punch” while maintaining ample extension so the musically important fundamentals are solidly and accurately reproduced. With an impressive combination of low-frequency extension and musical accuracy, the GP118-sw is an ideal companion to QSC’s WideLine Series, ILA Series, AcousticPerformance Series and AcousticDesign Series loudspeakers.

The GP118-sw features an 18-inch transducer that incorporates a double layer spider and triple roll surround for extended and controlled excursion at extreme power. The 4” voice coil is wound on a fiberglass former to prevent deformation at high operating temperatures and is extensively vented to reduce power compression. An aluminum demodulating ring is employed to further reduce distortion.

The GP118-sw is housed in an 18mm Baltic birch plywood enclosure and finished in an environmentally friendly, waterborne, polymer finish rugged enough for the demands of everyday use while also being field repairable. Internal bracing is employed to eliminate acoustic losses due to panel resonance while maintaining the enclosure’s robustness. It is available in a black or white finish.

• Premium-grade, long excursion, high power 18-inch transducer with 4-inch voicecoil, dual layer spider and triple-roll surrounds.
• Interlocking feet and recess features allow for rigid vertical stacking.
• Built-in handles for ease of transport.
• Threaded pole cup for deploying a full-range loudspeaker on top.
• M10 fittings allows for suspension in permanent and portable applications.
• Dual NL4 Speakon connectors.
• 18mm Baltic birch plywood construction.
• 16-Gauge powder coated steel grilles.
• Available in black and white.
• Complete EASE, CAD & BIM information available online.
• Cinema-version available for surround LFE.
