By QSC Audio

QSC WL118-sw WideLine Series 18 inch Subwoofer (Discontinued)

Name: QSC WL118-sw WideLine Series 18 inch Subwoofer (Discontinued)
Brand: QSC Audio
SKU: QSC-WL118-SW

Write a Review

Part #:

WL118-SW

Model #:

WL118-SW

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The QSC WL118-SW is a single 18" version of the popular WideLine-10 touring, dual 18" subwoofer and offers an impressive combination of punch and low-frequency extension.

Description

ILA subs may be suspended at the top of an ILA array using the standard FP2082-i array frame. When trim height is limited, the ILA sub may be suspended behind the array using the available EB2082-i extension bar.

Features

Single 18" subwoofer in a bass-reflex enclosure.
850 watt continuous power capacity.
Frequency range down to 29 Hz.
May be suspended at the top, or behind the WL2082-i array.
Available in black or white to harmonize with venue décor.

Specifications

Transducers
Configuration	Vented box
Low-frequency	850 W, 8Ω 18" woofer with a 4" voice coil, ceramicmagnet assembly
Frequency Response (±3 dB)	32 Hz – 200 Hz
Frequency Range (-10 dB)	29 Hz – 800 Hz
Nominal Impedance	LF: 8Ω
Continuous Power Capacity1/ Recommended Power	LF: 850 W / 1750 W
Sensitivity (1 W at 1 m)	LF: 98 dB
Maximum Output Continuous / Peak (SPL at 1 m)	LF: 128.5 dB / 134.5 dB
Cabinet Type	Vented subwoofer
Enclosure Material	18 mm Baltic birch plywood
Grille	16 gauge powder-coated steel with cloth backing
Connectors	2 x NL8 in parallel / 2 x NL4 in parallel
Pin Outs
1+/1-	Sub
2+/2-	Pass thru
3+/3-	Pass thru
4+/4-	Pass thru
1+/1-	Sub
2+/2-	Pass thru
Attachment Points	Integral, non-adjustable (straight array only)
Finish	Available in black (WL118-sw BLK) or white (WL118-sw WHT) paintable
Dimensions	22.1" H x 27.6" W x 30.3" D (562 mm x 702 mm x 771 mm)
Net Weight	111 lbs (50.4 kg)
Shipping Weight	121 lbs (55 kg)
