QSC TMR-2 TouchMix-30 Pro Rack Mount Kit (Discontinued)

Rack-mount adaptor kit to rack the TouchMix-30 Pro digital mixer in a standard 19" universal rack. Includes installation instructions and screws.

• Use a Phillips screwdriver to remove the three panhead screws (1) from each side of the mixer as shown
• Align the mounting pins on the bracket (2) with the screw holes on the mixer, then slide the mounting pins into the holes
• Use a Phillips screwdriver to install one M5 25mm fl athead screw (3) through each mounting pin in both brackets and into the mixer
• Tighten the screws. Do not overtighten
• Mount the mixer in your mixer rack using the three holes in each mounting bracket and the proper screws for the mixer rack

Quick Start Guide

• (2) Rack Mounting Brackets
• (6) Flathead Screws (M5 25 mm)
