The TP-BN14 is a bidirectional Dante network interface designed for tabletop use in conference rooms, meeting halls, or courtrooms. It features a shock-mounted XLR microphone input with automatic gain for dynamic or condenser microphones, P48 phantom power, and a front-panel mute button. A 2W RMS amplified speaker provides accurate monitoring of a dedicated audio mix.
A front-panel headphone output includes a four-source selector with LED indicators for easy monitoring. The output level is controlled via a long-life front-panel potentiometer operating a VCA, ensuring noise-free adjustment over years of use. The headphone output supports high- or low-impedance headphones and can be used for simultaneous monitoring or language translation applications.
The TP-BN14 operates from PoE or an external 24 Vdc supply and features high-resolution 24-bit analog-to-digital and digital-to-analog conversion. Compact and versatile, it provides professional-grade Dante connectivity and monitoring in a single, tabletop-ready device.
| Network Connector | RJ45 Ethercon style |
|---|---|
| Digital Audio Protocol | Dante |
| Transmission Rate | 100 Mbps |
| Sample Rates Supported | 44.1 kHz, 48 kHz (default) |
| Bit Depth | 24-bit |
| Mic Input | Balanced XLR with P48 phantom power |
| Mic Gain | Automatic; 40 dB (condenser), 60 dB (dynamic) |
| Headphone Output | Stereo mini-jack, 90 mW per channel, 20 Hz - 20 kHz |
| Headphone Source Selection | 4 Dante sources with LED indicators, momentary pushbuttons |
| Speaker Output | 2 W RMS, 150 Hz - 20 kHz |
| Muting | Front-panel mute button toggles mic on/off |
| Power Requirement | 24 Vdc @ 300 mA or PoE Class 0, IEEE 802.3af |
| Dimensions (H x W x D) | 2.85" (72.39 mm) x 6.95" (176.53 mm) x 7" (177.8 mm) |
| Shipping Weight | 3.26 lbs (1.48 kg) |
