Renkus-Heinz IC215S-R Dual 15" Subwoofer (Discontinued)

Name: Renkus-Heinz IC215S-R Dual 15" Subwoofer (Discontinued)
Brand: Renkus Heinz
SKU: RENKUS-IC215S-R

Write a Review

Part #:

IC215S-R

Model #:

IC215S-R

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The IC215S Series subwoofers are perfect companions to the Iconyx IC Live arrays.

Description

IC215S Series subwoofers are perfect companions to Iconyx IC Live arrays. Their dual 15-inch subwoofers deliver outstanding low frequency impact with a high-order bandpass design that maximizes the efficiency of its cutting edge woofer technology and Class D amplifier.

IC215S series subwoofers are available in two versions, one designed expressely for portable use and the other for permanent installations. Both versions are fully integrated into the RHAON (Renkus-Heinz Audio Operations Network) for flexible analog and digital audio signal distribution.

Features

Transparent Solutions

Corporate Events
Live Concerts
Political Rallies
Theatrical Productions
Museums: lobbies, galleries, etc
Resorts, Theme Parks
Any environment where enjoyable music and/or intelligible speech are critical

Adaptable, Articulate, Invisible
Powerful, Accurate Sub-Bass Performance
Portable, Scalable, Versatile
RHAON Empowered

Specifications

Sensitivity	1.4V (for Rated Power Output)
Frequency Range	43 Hz to 100 Hz
Max SPL	133 dB Pgm, 136 dB Peak
Transducers	Two Model SSL 15-14, 15" Cone Woofers, 800W Pgm @ 4 Ohms (Each)
Power Required	09/136V or 180/260V AC, 50/60 Hz, 13 Amps @ 120V, 6.5 Amps @ 240V
Inputs	Analog Audio Input 1: Looping XLR (Female in, Male Out) Analog Audio Input 2: Phoenix 6-pin (Looping 3-in, 3-Out) CobraNet: Dual RJ45 Connectors (For CAT5 Copper Cable) AES/EBU: Phoenix Connector
Controls (Rear Mounted)	Power On/Off, Push-To-Reset Circuit Breakers
Computer Controls	Gain, Mute, On/Standby, Input Selection; Compression, 8-Band Parametric EQ, Shelving & Roll off Filters, Delay
Status Indicators	Power, Signal, Overdrive, Thermal, Mute, Input Pad
Power Connector	Powercon Locking Connector
Network Digital Format	16, 20 or 24 bit PCM; 48 or 96 kHz Sample Rate; Selectable Network Latency
Hardware	Aeroquip Flytrack, Handles, Casters
Enclosure	Finnish Birch, Perforated Steel Grille
Finish	Black Paint
Dimensions (H x W x D)	44.5" (1130 mm) x 20" (508 mm) x 24" (610 mm)
Net Weight	208 lbs (94.4 kg)
