Renkus Heinz IC118S-R 18 inch Subwoofer

Home /
Renkus Heinz IC118S-R 18" Subwoofer (Discontinued)

Description

Details

The IC118S-R subwoofer adds powerful sub-bass to an IC Squared system. Its high-power 18-inch woofer delivers outstanding low frequency impact with a highorder bandpass design that maximizes the efficiency of their cutting edge woofer technology and Class D digital amplifiers.

Specification

Sensitivity	M1.4V (for Rated Power Output)
Frequency Range	32 Hz to 120 Hz
Max SPL	130 dB Peak
Transducer	Model SSL 18-6, 18" Woofer, 800W Pgm @ 4 Ohms
Power Required	90/136 V or 180/260 V AC, 50/60 Hz 13 A @ 120 V, 6.5 A @ 240 V
Inputs	Analog Audio & AES: Looping XLR (Female In, Male Out) Phoenix 6-Pin (Looping 3-In, 3-Out) CobraNet: Dual RJ45 Connectors (for CAT 5 Cable)
Power Connector	Powercon Locking Connector
On-Board Controls	Mute Button, Up & Down Output Level 10 dB Input Pad (On Analog 1 Input) Circuit Breaker
Computer Controls	Gain, Mute, On/Standby, Input Selection, Compression, 8-Band Parametric EQ, Shelving & Rolloff Filters Delay
Status Indicators	Power, Signal Overdrive, Thermal, Mute, Input Pad, Failure
Digital Format	16, 20 or 24 Bit PCM; 48 or 96 kHz Sample Rate; Selectable Network Latency
Amplifier	PM-2LR
Hardware	16 Metric M10 Attachment Points Interlocking IC² Flying Hardware
Enclosure	Finnish Birch, Perforated Steel Grille
Finish	Black Paint
Dimensions (H x W x D)	23" (584 mm) x 28.5" (724 mm) x 30" (762 mm)
Weight	209 lbs (95 kg)
