Rolls PS16 Personal Monitor Power Center (Discontinued)

Rolls PS16 Personal Monitor Power Center (Discontinued)

Name: Rolls PS16 Personal Monitor Power Center (Discontinued)
Brand: Rolls Audio
SKU: ROLLS-PS16
Price: 79 USD
Availability: OutOfStock

Write a Review

Part #:

PS16

Model #:

PS16

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Rolls PS16 supplies power and distributes a single Monitor signal to up to eight Rolls PM50se, PM50s, PM55, or PM351's with only one cable ran to each item. This dramatically increases efficiency and eliminates the need for multiple adapters and cables.

Description

Rolls PS16 Personal Monitor Power Center for PM Series

The PS16 supplies power and distributes a single Monitor signal to up to eight Rolls PM50se, PM50s, PM55, or PM351's with only one cable ran to each item. This dramatically increases efficiency and eliminates the need for multiple adapters and cables. The power AND monitor signal are carried from each PS16 output using an ordinary TRS 1/4" stereo cable to the Monitor input of the PM50s, PM50se, PM55, and PM351. Using stereo "Y" adapters, up to eight of the Personal Monitor Amplifiers may be connected.

Features

Supplies power for up to ten PM50s,PM50sOB and PM350 units
Directly supplies a monitor signal to the above listed units
Unbalanced 1/4" and transformer-balanced XLR inputs
External Power Supply included for low noise operation

Specifications

Audio Input	Line Level XLR Balanced, 1/4" Unbalanced Phone (mono)
Input Power	12 VAC, 700 mA
Output Power	12 VDC on the Ring terminal of each OUT jack
Dimensions (H x W x D)	3.13" (79.38 mm) x 3.13" (79.38 mm) x 1.25" (31.75 mm)
Weight	1 lbs (0.45 kg)
