The RM64 four zone mixer combines two paging microphones with up to four line level source inputs. Each input is switch selected to output to any combination of four zone outputs. The outputs are all balanced XLR connectors, and a 1/4" Remote Volume jack provides each zone with the means for external volume control. The Microphone inputs feature automatic ducking for easy paging. The RM64 is the ideal solution for banquet rooms, offices, restaurant/nightclubs, etc.
| Input Impedance | 10K Ω balanced50K Ω unbalanced RCA |
|---|---|
| Output Impedance | 50 Ω Balanced XLR |
| Max Input Level | Mic: +10 dBSource: +22 dB |
| Phantom Power | +12 Volts DC, 5mA max |
| Input Connectors | XLR and RCA |
| Outputs | 4 ea. XLR |
| Max Gain | 60 dB mic30 dB line |
| S/N Ratio | >75 dB |
| THD | < .3% |
| IMD (SMPTE) | < .3% |
| CMRR | 90 dB |
| Frequency Response | 20Hz to 20kHz +/- 0 dB |
| Power | 120 VAC 50-60 Hz, 15 W |
| Dimensions | 19" (480 mm) x 1.75" (45 mm) x 6.5" (170 mm) |
| Weight | 7 lbs (3 kg) |
