Samson S-Zone 4-Input Channels 4-Zone Commercial Stereo Mixer

The Samson S-zone gives system installers all the features they need to control up to four zones of audio with a compact, single rack space unit. It features two balanced mic and four stereo aux/line inputs with a unique front panel control section that allows you to assign any of the four inputs to any of the four zones with just the push of a button. The front panel layout also has input and output volume controls, independent 2-band equalization, and an on-board speaker for selectable zone monitoring.

A six-segment LED bar VU meter is present on all outputs providing a visual display of the level of each zone. Perhaps the most unique feature of the S-Zone is it's front panel monitor section. The zone assignment switch, headphone jack, level control and internal super speaker allow you to monitor the signal that is playing in any zone directly on the S-Zone, without having to physically be in the room that signal is playing in. The handy scribe strip for both the inputs and outputs make it easy to label the connected gear and the rooms the S-Zone is feeding. For easy installation, all the S-Zone connections are made with standard Euroblock connection strips.

A remote Volume Control for each Zone Output, up to 3000 feet in distance is possible using a standard 100k linear taper potentiometer and three-conductor shielded wire.
