Allen & Heath GR05 5-Input 4-Output Analogue Zone Mixer (Discontinued)

The Allen & Heath GR05 is a 5-input, 4-output analogue zone mixer for sound installations requiring 2 mic and 3 stereo line to up to 4 mono or 2 stereo zones. Internal jumpers allow custom configuration protected for day-to-day operation by non-technical staff. Zone volume may be remotely controlled.

The GR05 has 2 microphone inputs and 3 stereo line inputs. These can be assigned to 4 zone outputs configurable in mono or stereo pairs and controlled by front panel or remote level controls.

Ducking, EQ and muting can be configured. Further inputs and outputs are possible using the expander system.

GR05-ST version also available, with XLRs replaced by Euroblock (Phoenix) connectors.

• 2 mic inputs
• 3 stereo inputs
• 4 XLR outputs
• Routing Matrix
• Remote Control
• Ducking
• Expandable
• Lock out system
• Internal power supply
