Samson Stage v266 Dual Handheld Wireless System (Discontinued)

Part #:
SWV266SHT6U
Model #:
Stage v266
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

Designed for twice the versatility, Samson’s Stage v266 Dual Handheld Wireless System let’s you use two microphones simultaneously with a single receiver. It’s the ideal wireless solution for two vocalists, karaoke, DJs or any application where two mics are needed.

Description

The Samson Stage v266 Dual Handheld Wireless System lets you use two microphones simultaneously with a single receiver. It’s the ideal wireless solution for two vocalists, karaoke, DJs or any application where two mics are needed.

At the core of the Stage v266 system is the SR266 half-rack dual VHF wireless receiver. The receiver’s front panel features an RF channel indicator and a large rotary volume knob for each channel. Its rear panel offers two tuned antennas, as well as two 1/4" outputs that allow for both mix and individual channel output options. The Stage v266 system comes with a 1/4" to 1/4" and a 1/4" to RCA cable.

The Stage v266 system includes two HT6 handheld microphone transmitters, each with an H6 dynamic microphone element to capture clear, accurate vocals. Each transmitter operates for up to ten hours on a single 9 V battery (two included) and offers a handy audio on/off switch. With the meticulous engineering, state of the art technology and impressive audio capabilities that are built into every Samson wireless system, the Stage v266 system ensures crystal clear operation and the most dependable dual-channel performance available.

The beauty of the Stage v266 system is that you can have both channels running simultaneously. This makes it perfect for a variety of scenarios where multiple voices exist, including bands with multiple singers. Beyond the system’s ability to capture stunning vocals in musical settings, Stage v266 allows bands, duos and other small musical groups to add energy and movement to their performances.

Features

  • SRv266 half-rack dual VHF wireless receiver
  • Two HT6 dynamic handheld microphone transmitters, each with H6 dynamic microphone element
  • Each transmitter operates for ten hours on a single 9 V battery
  • Great RF reception for interference-free performance
  • Two 1/4" outputs feature mix and individual channel output options
  • Includes 1/4" to 1/4" cable, 1/4" to RCA cable, AC adapter and two 9 V batteries

Specifications

Operating Frequency VHF 173.80 MHz to 213.20 MHz
Number of Channels Fixed channel
Frequency Stability ±0.005%
Modulation Mode FM
Maximum Deviation ±15 kHz
Operating Range 250’ (line of sight)
Operating Temperature Range 40° F (4° C) to 110° F (43° C)
Frequency Response 80 Hz to 15 kHz
Image Rejection 30 dB
Dynamic range 95.5 dB
Maximum Output 900mV
Sensitivity 10 dBμV for 48 dB S/N
Output Connectors Two - 1/4” TS (“mono”) phone jack
Audio Output Levels -10dB unbalanced (1/4” phone connector)
Power Supply 100-240 V AC (50/60 Hz) to 12V DC 0.2A
RF Power Output 10 mW
Microphone Element H6 Dynamic unidirectional
Typical Battery Life (9 V alkaline battery) 9-hours
Current Consumption 30 mA typical
Receiver (H x W x D) 1.7” (43 mm) x 7.9” (200 mm) x 5.3” (134 mm)
Transmitter (Diameter x D) 2.1” (52.6 mm) x 9.3” (235.5 mm)
Receiver 0.84 lbs (0.38 kg)
Transmitter 0.4 lbs (0.18 kg)

System Includes

  • (1) SR266 Receiver
  • (2) HT6 Handheld Transmitter
