Shure KSM32/CG Embossed Cardioid Condenser Microphone

Name: Shure KSM32/CG Embossed Cardioid Condenser Microphone
Brand: Shure
SKU: SHURE-KSM32/CG
Price: 659 USD
Availability: InStock

Write a Review

Part #:

KSM32/CG

Model #:

KSM32/CG

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Shure KSM32 is a side-address, cardioid condenser microphone for highly critical studio recording and live sound productions.

Description

The Shure KSM32 is a side-address, cardioid condenser microphone for highly critical studio recording and live sound productions. It offers an extended frequency response for an open, natural sounding reproduction of the original sound source. The KSM32/CG has a non-reflective, charcoal-gray finish for situations where less microphone visibility is preferred, such as live sound and stage production. It comes with the following accessories: ShureLock™ swivel mount and Padded, zippered carrying bag. Also available in Charcoal Gray finish.

Features

Class A, transformerless preamplifier circuitry eliminates cross-over distortion for improved linearity across the full frequency range.
Embossed, high-compliance diaphragm provides extended low-frequency response.
Ultra-thin, gold-layered, low-mass, Mylar® diaphragm for excellent transient response
15 dB attenuation switch for handling.
Extremely high sound pressure levels (SPL).
Switchable low-frequency filter provides greater flexibility to reduce background noise or to counteract proximity effect.
Integrated three-stage pop protection grille reduces "pop" and other breath noise.
Internal shock mount reduces transmission of handling noise.

Specifications

Cartridge Type	Permanently-biased Condenser
Frequency Response	20 to 20,000 Hz
Directional Polar Pattern	Cardioid
Output Impedance	150 Ω (actual)
Low Frequency Response Switch	flat; -6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power	48 Vdc ±4 Vdc (IEC-268-15/DIN 45 596), positive pins 2 and 3
Current Drain	4.65 mA typical at 48 Vdc
Common Mode Rejection	≥ 50 dB, 20 Hz to 20 kHz
Polarity	Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL)	-36 dBV/Pa (16 mV)
Maximum SPL at 1000 Hz 2500 Ω load (Attenuator on) 1000 Ω load (Attenuator on)	139 (154) dB 133 (148) dB
Signal to Noise Ratio	81 dB
Finish	The KSM32/CG has a non-reflective, charcoal-gray finish.
Accessories	ShureLockTM swivel mount Padded, zippered, carrying bag
Dimensions	55.9 mm (2.20 in.) maximum body diameter, 187 mm (7.37 in)
Weight	490 grams (17.3 oz.)
