Shure SLX4L Single Channel Diversity Receiver with Logic Output (Discontinued)

Description

Details

The Shure SLX4L available with logic output for use with software echo cancellation and remote battery life monitoring. Logic-enabled transmitters include MX690 and MX890.

The logic capability of the SLX4L receiver provides two functions: Transmitter Mute Status indication (which can be used to signal and control other events) and Transmitter Battery status indication.

The Shure SLX4 receiver brings unprecedented ease of use to wireless with Automatic Frequency Selection and Automatic Transmitter Setup. For use with SLX Wireless.

With included rack hardware and detachable antennas, it is ready for immediate installation right out of the box.

Features

Features

Logic functionality for software echo cancellation and remote battery life monitoring
Automatic Frequency Selection
Automatic Transmitter Setup
960 Selectable frequencies across 24 MHz bandwidth
Detachable 1/4 wave antennas
Microprocessor-controlled diversity
RF presence LED
5-segment audio meter
Multi-function, backlit LCD
Low battery indicator
Frequency and power lockout
Rugged metal chassis
Volume control on rear of unit
1/2 rack design
Furnished rack hardware
Non-slip bumpers for use out of rack
XLR and 1/4" outputs

Specification

Sensitivity	–105 dBm for 12 dB SINAD, typical
Power Requirements	12–18 Vdc at 150 mA, supplied by external power supply
Configuration	Impedance balanced
Maximum Audio Output Level Ref. ±38 kHz deviation with 1 kHz tone	XLR connector (into 600 Ω load): –13 dBV 1/4" (6.35 mm) connector (into 3 kΩ load): –2 dBV
Impedance	XLR connector: 200 Ω 1/4" (6.35 mm) connector: 1kΩ
Pin Assignments	XLR connector: 1=ground, 2=audio, 3=no audio 1/4" (6.35 mm) connector: Tip=audio, Ring=no audio, Sleeve=ground
Image Rejection	>70 dB, typical
Volume Adjustment Range	0 dB to -25 dB
Dimensions (H x W x D)	1.65" (42 mm) x 7.76" (197 mm) x 5.28" (134 mm)
Weight	1.79 lbs (816 g)
Housing	Galvanized steel
