The SoundTube IPD-SM52-EZ-II is a Dante-enable, digital end-point solution in a surface-mount loudspeaker. This speaker is Dante addressable and includes a 40W PoE amplifier for simplified installation and set up. Driver components consists of one 5.25 inch polypropylene woofer and one 1.0 inch soft dome tweeter in a ported enclosure. The included pre-mountable surface-mount bracket allows for quick and easy installation and the powder-coated aluminum grille keep the speaker looking good in most environments. The system is UL 60065 approved. Included accessories: Safety cable, wall mount bracket, conduit connector and optional port plug.
| Frequency Response (-3 dB) | 65 Hz - 20 kHz | Sealed: 80 Hz - 20 kHz |
|---|---|
| Low Frequency (-10 dB) | 55 Hz - 20 kHz | Sealed: 62 Hz - 20 kHz |
| Max. SPL dB @ 1 M RMS | 97 dB |
| Low-Frequency Driver | 1 x 133.0 mm (5.25 in) polypropylene cone, butyl rubber surround |
| High-Frequency Driver | 25.0 mm (1.0 in ) soft dome tweeter |
| Network Type: Low-Pass | 12 dB per octave, 2nd order |
| Network Type: High-Pass | 12 dB per octave, 2nd order |
| Enclosure Material | High Impact Poly Styrene (HIPS) |
| Grille | Aluminum with powder-coat finish |
| Colors | Black or white |
| Dimensions (H x W x D) | 11.88" (301.63 mm) x 7.5" (190.5 mm) x 6.63" (168.28 mm) |
| Weight | 7.4 lbs (3.35 kg) |
| Shipping Weight | 9.4 lbs (4.26 kg) |
