SoundTube XT550 5.25" 2-Way Outdoor Speaker - Green

Name: SoundTube XT550 5.25" 2-Way Outdoor Speaker - Green
Brand: SoundTube
SKU: SOUNDT-XT550-GN
Price: 648 USD
Availability: InStock

Write a Review

Part #:

XT550-GN

Model #:

XT550

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

The SoundTube XT550 is a premium 2-way outdoor loudspeaker solution for installations requiring high-performance sound in a durable speaker design. Not only is it UV resistant, scratch resistant, chlorine resistant, and weather resistant with professional-grade components for long-lasting performance and durability, the XT550 is designed for full-range back-ground and foreground music as well as paging. The speakers sealed, in-ground enclosure design delivers true low-end response (38 Hz, 10 dB) and optimal off-axis performance. The XT550 includes theft-resistant mounting hardware and a weatherproof 5-position tap switch for 25/70.7/100 Volt applications with transformer bypass position.

Features

Patented BroadBeam® 360° dispersion pattern delivers smooth off-axis coverage and reduces overall system costs
Professional-grade components and construction for lasting performance and durability
Water-resistant construction with liquid-tight compression fittings
Protection from UV rays, weather and weed-wackers
Patented ZeroReflection™ enclosure enhances bass performance
5-Position tap switch for 4 Ohm or 25/70.7/100 V applications
Multiple inputs for fast and easy daisy-chaining of multiple speakers

Specifications

System Type	5.25" Coax outdoor (32 Watt transformer for 25/70.7/100 Voltor voice coil/8 Ohm direct)
Frequency Response (- 3 dB)	75 Hz - 12 kHz port open (101 Hz - 12 kHz port closed)
Low Frequency (-10 dB)	62 Hz - 22 kHz port open (62 Hz - 22 kHz port closed)
Max. Program Power	120 Watts
Max. Continuous Power RMS	60 Watts
Max. SPL dB @ 1 M	107.5 dB
Sensitivity dB @ 1W/1M	88.5 dB
Impedance	4 Ohms (nominal)
Coverage Angle (-6 dB @ 2 kHz)	360º Horizontal - 40º Vertical
Coverage Angle (-6 dB @ 10 kHz)	360º Horizontal - 40º Vertical
Tap Selector	5-Position rotary switch with voice coil direct (4 Ohm)
Low-Frequency Driver	1 x 133 mm (5.25 in) Polypropylene cone, butyl rubber surround
High-Frequency Driver	1 x 25 mm (1") Aluminum dome
Low-Frequency Voice Coil	1" (25 mm)
Low Pass	6 dB per octave, 1st order
High Pass	6 db per octave, 1st order
Crossover Frequency	3.0 kHz
Enclosure Material	Roto-molded polyethylene plastic
Grille	Stainless-steel with powder-coat finish
Inputs	18-Gauge wire lead
Dimensions (Dia x H)	14.17" (359.9 mm) x 16.42" (417.1 mm)
Weight	13 lbs (5.9 kg)
Shipping Weight	19 lbs (8.6 kg)
