- Description
Details
The Stewart Audio CVA50-1 Mono Sub Compact Amplifier is built to meet the rigorous demands of high quality commercial, industrial and Pro Audio sound installations. Its low cost, lightweight and convection cooling make this Class D amplifier flexible enough for a broad range of applications requiring quiet amplification. With an extremely compact form factor, the CVA's allow amplification to be located in places normally off limits to standard amplifiers without compromising sound or power. The Plenum rating (UL 2043) and remote volume control further compliment the recessing options. Our Signal Sense Power Technology™ (SSPT™) ensures the amplifier is only powered when there is a signal present, saving energy and extending product life. Like all Stewart products, the CVA's are designed for sonic accuracy, high efficiency and extended duty cycles.
- Features
Features
- Sub Compact 1/4 rack package
- Mono constant voltage amplifier (70V or 100V)
- Music and fire alarm muting
- Clean full-range dynamic power
- Signal Detect trigger for sleep & wake up
- Specification
70V/100V Power Output 50W Frequency Response (+0, –3 dB, 1W) 100 Hz—20 kHz Power Bandwidth (+3, –3 dB) 80 Hz—30 kHz THD+N <.1% @ Full Power Signal-to-Noise Ratio >80dB Remote Volume Control 0-10V DC Input Sensitivity .5V (-3 dBV) Standard Voltage Gain 151X (43dB) @ 70.7V Out Input impedance (Balanced/Unbalanced) 20k Ohms/10k Ohms Standby, Idle Current Draw, 1/8 Power Draw 0.005/ 0.01/0.15 Amps Class D Input Connectors Euro Block 3-Pin, 3.5mm Output Connectors Euro Block 2-Pin, 5mm Power Supply External in-line 48VDC (Included), 2-pin Euro Block Cooling Convection–Cooling (No Fans) Controls Level LED Indicators Power, Signal Present & Clip Construction Aluminum Chassis Plenum Rating UL 2043 Approved Dimensions (H x W x D) 1.25" (31.75 mm) x 4.35" (110.49 mm) x 3.2" (81.28 mm) Weight 1.2 lbs (0.54 kg) - Documents
Documents
