Stewart Audio CVA50-1 NET+ Mono Dante Subcompact Amplifier

Home /
Stewart Audio CVA50-1 NET+ Mono Dante Subcompact Amplifier (Discontinued)

Description

Details

The CVA50-1 NET+ is subcompact 50W mono 70V/100V networkable power amplifier built to meet the rigorous demands of high quality commercial, industrial and Pro Audio sound installations. The CVA50-1 NET+ version is designed with a network and local legacy inputs. A priority switch on the rear allows for selective ducking of either signal to allow one amplifier to do the work of two. These versatile dual input amplifiers allow for legacy audio devices to be used in a local setting while still having the flexibility of utilizing a networked signal. By setting the priority to local, the network could play background music until a signal is detected on the local inputs from a TV in a lobby. If the priority is set to network, a page could duck the TV output in a training room. These lightweight Class D amplifiers straddle the digital divide using all the benefits of the networked audio and while allowing for legacy device use.

Features

Features

Mono networked endpoint
Remote volume control and muting
External inline power supply

Specification

CVA50-1 100V/70V	50W
Frequency Response (+0, -3 dB)	100 Hz - 20 kHz
Power Bandwidth (+3, -3 dB)	80 Hz - 30 kHz
THD+N	<.1%
Signal-to-Noise Ratio	>80dB
Remote Volume Control	0-10V DC, 4 Pin Euro Block
Input Sensitivity	.5V (-3 dBV)
Standard Voltage Gain	151X (43dB) @ 70.7V out
Input impedance (Balanced/Unbalanced)	20k Ohms/10k Ohms
Sleep, Idle Current Draw, 1/8 Power Draw	3.3 / 6.9 / 14.2W
Class	D
Input Connectors	RJ45, Euro Block 3 Pin, 3.5mm (NET+)
Output Connectors	Euro Block 2 Pin, 5mm
Power Supply	External in-line 48VDC (Included), 2 pin Euro Block
Cooling	Convection-Cooling (No Fans)
Controls	Level (NET+)
LED Indicators	Power, Signal Present & Clip
Construction	Aluminum Chassis & Top Cover
Dimensions (H x W x D)	1.25" (32 mm) x 6.00" (152 mm) x 4.00" (102 mm)
Weight	<1.2 lbs (0.54 kg)
