Tannoy 110TB-P Compact Tile Bridge Subwoofer

Home /
Tannoy 110TB-P Compact Tile Bridge Subwoofer (Discontinued)

Description

Details

The Tannoy 110TB Tile Bridge subwoofer, like its companion subwoofer the 110SR (Sheet Rock), is capable of extended frequency range from 31 Hz - 150 Hz @ -3 dB (active), 41 Hz - 150 Hz @ -3 dB (passive).

Easy to install and with no special construction requirements, the 110TB drops into a 2’ x 2’ ceiling tile space. It integrates invisibly into the environment by using a standard air conditioning vent cover as a speaker grille.

The 110TB features a resonance decoupling system, and each corner of the cabinet is fitted with a seismic tether point. The four corner flying points allow the unit to be flown in free space via a 3/8” threaded rod, a chain or aircraft cable. Fire rating is NFP-A Grade A.

The 110TB incorporates an 203 mm (8.00)” x 254 mm (10.00)” input module located on the side of the cabinet. The input module controls are easily accessed by lifting the adjacent ceiling tile.

The 110TB can be ordered with a passive input module (110TB-P) connected via barrier strip, or with a passive internal crossover (110 TB-PX). Both passive modules can be powered by a THP 60 Watt / 70 Volt line transformer for distributed systems (110TB-P70 V and 110TB-PX70 V).

Features

Features

10.00" (254mm) bass unit
Easy access to system controls
Input module options - system flexibility
Seismic tether points
Eye bolts and threaded rod inserts for "free space" suspension
Class A fire hazard classification paint
Quick & easy mounting
200 Watts - 8 Ohms load
L/R fully balanced inputs & outputs
Variable low pass
Fixed 80Hz high pass output available

Specification

Frequency Response
Active	(-3dB): 31Hz - 150Hz (-10dB): 26Hz
Passive	(-3dB): 41Hz - 150Hz (-10dB): 32Hz
Rated Maximum SPL @ 1 m	105dB (average) 111dB (peak)
Electronics
Input	3 pin XLR female; pin 2 positive
Sensitivity	500mV for rated output
Low Pass Filter	Fixed 12dB/oct @ 130Hz, with variable 12dB /oct, 50 - 150Hz
High Pass Filter	Fixed 12dB/oct @ 80Hz
Amplifier Type	Class AB Mosfet
Amplifier Output Power	200 Watts into 8 Ohms load
User Controls and Indications	Level, low pass frequency, bass boost. Pin 1 lift, phase +/- 180 degrees, low pass, all pass, power on/off
Construction
Driver Complement	10" (254 mm) bass unit
Enclosure	Direct radiating vented MDF
Connectors (Passive Modules)	Barrier strip
Finish	Textured Black
Dimensions (H x W x D)	9.9” (251.46 mm) x 23.54” (597.92 mm) x 23.54” (597.92 mm)
Weight	45 lbs ( 20.41 kg )
