Tannoy VNET2-Dante Bridge (Discontinued)
Part # 8001 7240
Model # VNET2-DANTE BRIDGE

The VNET2-Dante Bridge is a standalone device available from Tannoy, designed to facilitate integration of VNET2 products such as QFlex with Dante digital audio networks.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The VNET2-Dante Bridge is a standalone device available from Tannoy, designed to facilitate integration of VNET2 products such as QFlex with Dante digital audio networks. It is powered via PoE, or alternatively by an optional extra 12 V power supply.

Dante is an audio networking technology developed by Audinate. It allows many channels of uncompressed digital audio, and control data to be conveyed down a standard Ethernet network. The VNET2 Dante Bridge allows VNET2 devices to be seamlessly integrated into Dante systems with the minimum of fuss. Analog outputs also allow the Dante Bridge to be used with products that do not have VNET2 Interfaces, such as 1st generation VNET speakers and SC1 controllers.

Features

Features

  • 16 total inputs including XLR jacks w/ phantom power on ch. 1-4
  • On-board Alesis digital effects with 256 variations
  • Expanded channel count perfect for small groups or sub-mixes
  • 4 mic input channels with gold-plated XLR and balanced line inputs
  • Two stereo input channels with balanced TRS jacks
  • High headroom circuitry offering extra dynamic range
  • Ultra-low-noise discrete mic preamps
  • 3-band EQ on each channel
  • Footswitch input for effects on/off (sold separately)
  • 2 aux sends per channel for external effects and monitoring
  • 2-bus design with Main and Control Room 1/4" & rdquo; stereo outputs
  • Aux inputs/outputs for external audio source integration
  • Switchable phantom power
Specification
Ethernet
Compliance100 base T or 1000 base T
VNET
Cable typeCategory 5 UTP (or better)
Max. Total cable length1 km
Max. Network span1 km
ConnectorStandard RJ45
Ext PowerOnly to be provided by a Linea Research Accessory Power Supply via a 3.5 mm Jack-to-Jack lead (Line Research part no. LD1047)
Power
Consumption3W max
Analog Audio
Connector3-Pin locking male XLR
Frequency Response20 Hz to 20 kHz +-0.2 dB
THD<0.005% typ. at 1 kHz
Dynamic Range114 dB (A weighted)
Max. Output Level+ 10 dBu into 600 ohms
Environmental
Temperature0 to +45° C
Humidity0 to 80% RH (non-condensing)
Physical
Dimensions (H x W x D)1.7" (43 mm) x 4.5" (115 mm) x 4.5" (115 mm)
Weight1.1 lbs (0.5 kg)
