By Telex

Telex APS-1 Broadband Antenna Combiner Splitter for RadioCom Base TNC Connectors

Name: Telex APS-1 Broadband Antenna Combiner Splitter for RadioCom Base TNC Connectors
Brand: Telex
SKU: BOSCH-F.01U.412.387
Price: 416 USD
Availability: InStock

Write a Review

Part #:

F.01U.412.387

Model #:

APS-1

Current Stock:

Availability: Usually arrives in 10-15 business days

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Telex APS-1 is a 2:1 antenna splitter or combiner. This is a great solution to combine or distribute simple 2-up systems set-ups of BTR-800 or BTR-700. The APS-1 can be used with any UHF Telex RadioCom base.

Description

The APS-1 is a 2:1 antenna splitter or combiner. This is a great solution to combine or distribute simple 2-up systems set-ups of BTR-800 or BTR-700. The APS-1 can be used with any UHF Telex RadioCom base.

Features

Small Size, approximately 2" x 2"
Convenient TNC connectors (NO Coaxial Adapters Required)
Signal Loss: -3.5 dB
Frequency Range: 100 MHz to 900 MHz
Low insertion loss, 0.3 dB typ
Good isolation, 26 dB typ
Up to 5W power input as splitter
Excellent amplitude unbalance, 0.1 dB typ
Excellent phase unbalance, 1 degree typ
Rugged shielded case

Specifications

Frequency Range	100 MHz to 900 MHz
Isolation	23 dB typ.18 dB min.
Insertion Loss Above 3.0 dB	0.3 dB typ.1.0 dB max.
Phase Unbalance (degrees)	3 max.
Amplitude Unbalance	0.3 dB max.VSWR1.5:1 max.
Operating Temperature	-55° C to 100° C
Storage Temperature	-55° C to 100° C
Power Input	5W max.
Internal Dissipation	1W max.
Dimensions	2"W by 2"H (5.08 cm x 5.08 cm)
Shipping Dimensions	4"D x 3"W x 3"H (10.16 cm x 7.62 cm x 7.62 cm)
Weight	4 oz (113 g)
Shipping Weight	1 lbs (0.45 kg)
