The TOA BS-1030W is a 4-inch 2-way bass reflex universal speaker with selectable 100V and 8-ohm operation. Designed for paging and background music, it features IPX3 splash-proof protection, wide frequency response, and flexible mounting options for indoor and sheltered outdoor installations.

Description

TOA BS-1030W 4-Inch Bass Reflex Universal Speaker

The BS-1030W is a compact 4-inch 2-way bass reflex universal speaker designed to deliver clear speech and natural music reproduction in commercial audio applications. Its wide frequency response and efficient bass reflex design provide excellent sound quality for paging, background music, and public address systems. The clean white finish complements modern interiors and blends seamlessly into offices, retail stores, schools, hospitality venues, and other professional environments.

Designed for installation flexibility, the BS-1030W supports both 100V distributed audio systems and 8-ohm low-impedance operation, with convenient impedance selection via an integrated rotary switch. Multiple mounting options allow the speaker to be positioned for optimal coverage in a variety of installations, making it suitable for both permanent commercial AV systems and general-purpose sound reinforcement.

The speaker's IPX3 splash-proof construction allows installation in protected outdoor locations such as under eaves where it is shielded from direct rain exposure. Combining reliable performance, versatile installation options, and cost-effective operation, the BS-1030W is an ideal solution for everyday commercial paging and background music applications.

Features

  • 4-inch 2-way bass reflex universal speaker
  • Selectable 100V and 8-ohm operation via rotary switch
  • Designed for paging and background music
  • Wide frequency response for clear speech and music
  • Bass reflex enclosure for improved low-frequency performance
  • IPX3 splash-proof construction for sheltered outdoor installations
  • Suitable for indoor and under-eave installations
  • Multiple mounting options for flexible installation
  • Cost-effective commercial PA speaker
  • Ideal for retail, hospitality, education, offices, and public spaces
  • Durable white enclosure for professional installations

Specifications

Enclosure 2-way bass-reflex type
Rated Input 30W
Rated Impedance

100V line: 330Ω (30W), 500Ω (20W), 670Ω (15W), 1 kΩ (1W), 2 kΩ (5W)

70V line: 170Ω (30W), 250Ω (20W), 330Ω (15W), 500Ω (10W), 1 kΩ (5W)
Sound Pressure Level 90 dB (1W, 1 m)
Frequency Response 80 Hz - 20 kHz
Speaker Component 12 cm cone-type + dome-type
Speaker Cable 2-core cabtyre cord with diameter of 6 mm
Water Protection IPX4 (can be installed vertically or horizontally)
Operating Temperature 14°F to 122°F (-10°C to +50°C)
Finish Enclosure: ABS resin, white (RAL9010 Pure White), paint

Net: Surface treated steel plate, white (RAL9010 Pure White), powder coating

Bracket: Surface treated steel plate, white equivalent to RAL9010 Pure White, powder coating
Included Accessories Bracket × 1, Bracket mounting screw × 2, Bracket mounting washer × 2
Optional Accessories Mounting bracket: SP-420

Applicable bracket: WCB-13W, SP-410

Applicable stand: ST-16A
Dimensions (H × W × D) 11.42" (290 mm) x 7.72" (196 mm) x 5.90" (150 mm) (unit only)
Weight 5.51 lbs (2.5 kg)
