TOA F-08BT-WP-UE 8-Inch Weatherproof 2-Way Surface Mount Speaker

TOA F-08BT-WP-UE 8" IP65 Weatherproof 2-Way 70V/100V/8-Ohm Surface Mount Speaker - Black

【F-BOX】The Minds Behind The Product -TOA Corporation

TOA F-08BT-WP-UE 8" IP65 Weatherproof 2-Way 70V/100V/8-Ohm Surface Mount Speaker - Black

Name: TOA F-08BT-WP-UE 8" IP65 Weatherproof 2-Way 70V/100V/8-Ohm Surface Mount Speaker - Black
Brand: TOA Electronics
SKU: TOA-F-08BT-WP-UE
Price: 442 USD
Availability: InStock

Write a Review

Part #:

F-08BT-WP-UE

Model #:

F-08BT-WP-UE

Current Stock:

MSRP: $547.00

$442.00

Availability: Usually arrives in 5-9 business days.

Quantity:

Adding to cart… The item has been added

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The TOA F-08BT-WP-UE is an 8-inch IP65 weatherproof 2-way surface mount speaker with 120W program power and 70V/100V/8-ohm operation. Designed for powerful music playback and clear speech in demanding indoor and outdoor commercial installations.

Description

TOA F-08BT-WP-UE 8-Inch Weatherproof 2-Way Surface Mount Speaker

The F-08BT-WP-UE is a high-performance 8-inch 2-way surface mount speaker engineered to deliver powerful bass, crisp highs, and outstanding speech intelligibility in both indoor and outdoor commercial environments. Its sleek black enclosure blends into modern architectural spaces while providing premium audio performance for retail centers, hospitality venues, stadium concourses, transportation facilities, schools, and other large public areas.

Supporting 70V, 100V, and 8-ohm operation, the F-08BT-WP-UE provides exceptional flexibility for distributed and low-impedance sound systems. The included adjustable mounting bracket enables secure wall, ceiling, or pole installation, allowing installers to optimize speaker positioning while simplifying setup for a wide variety of applications.

Built for dependable long-term operation, the F-08BT-WP-UE features an IP65-rated weatherproof enclosure and EN 54-24 certification for voice alarm systems. Combining durable construction, wide coverage, and high-output audio performance, it is an ideal solution for professional commercial sound reinforcement where reliability and exceptional sound quality are essential.

Features

8-inch 2-way surface mount speaker system
IP65-rated weatherproof construction for indoor and outdoor use
Supports 70V, 100V, and 8-ohm audio systems
High-power performance for music and speech applications
EN 54-24 certified for voice alarm systems
Clear high frequencies with powerful low-frequency response
Wide, even sound coverage for large commercial spaces
Adjustable bracket for wall, ceiling, or pole mounting
Sleek black finish for modern architectural installations
Ideal for retail, hospitality, education, transportation, and public venues

Specifications

Enclosure	Sealed type
Power Handling Capacity	Rated noise power: 90W (8Ω), Continuous program: 180W (8Ω)
Frequency Response	70 Hz - 20 kHz, -10 dB at installation in 1/2 free sound field
Sensitivity	90 dB (1W, 1 m) (1 - 10 kHz, pink noise)
Rated Input	60W (100V line, 70V line)
Rated Input Impedance	8Ω 100V line: 170Ω (60W), 330Ω (30W), 670Ω (15W), 3.3 kΩ (3W) 70V line: 83Ω (60W), 170Ω (30W), 330Ω (15W), 670Ω (7.5W), 3.3 kΩ (1.5W)
Speaker Component	Low frequency: 20 cm (8") PPcone-type High frequency: 25 mm (1") dome tweeter
Directivity Angle	Horizontal: 100°, Vertical: 100°
Crossover Frequency	3 kHz
Compliance/Certifications	EN 54-24:2008, UL 1480A (UEAY) (outdoor use)
IP Code	IP65
Installation Environment	Indoor installation, Outdoor installation
Input Terminal	M4 screw terminal (distance between barriers: 9 mm)
Operating Temperature	-10°C to +50°C
Accessory	U-bracket x1 Speaker bracket x2 Bracket fixing screw set x1 Terminal cover x1 Terminal cover mounting screw x4
Finish	Aluminium, black (RAL 9011 or equivalent)
Dimensions (H x W x D)	15.43" (392 mm) x 9.88" (251 mm) x 8.5" (216 mm)
Weight	12.13 lbs (5.5 kg)
