Space diversity reduces a fading effect of a received signal and generates a constant output regardless of a variation of a signal-to-noise ratio of the received signal. The space diversity receiver compares a signal-to-noise ratio of a signal received from a first antenna and a signal-to-noise ratio of a signal received from a second antenna, so as to amplify the received signal having a higher signal-to-noise ratio and attenuate the received signal having a lower signal-to-noise ratio. The amplified signal is combined with the attenuated signal.
| Power Source | AC mains (Supplied AC-DC adapter must be used) |
|---|---|
| Power Consumption | 200 mA (12 V DC) |
| Receiving Frequency | 636-666 MHz, UHF |
| Selectable Channel | 64 selectable frequencies |
| Diversity System | True diversity |
| Mixing Output | MIC/LINE (selectable): -60 dB (MIC)/-20 dB (LINE), 600 Ω phone jack (unbalanced), 600 Ω XLR-3-32 type connector (balanced) |
| Mixing Input | –20 dB, 10 kΩ, unbalanced, phone jack |
| Antenna Input | 75Ω, BNC (phantom powering for antenna), 9 V DC, 30 mA (max) |
| Receiving Sensitivity | Over 90 dB, S/N ratio (20 dBμV input, 40 kHz deviation) |
| Squelch Sensitivity | 18 – 40 dBμV variable |
| Squelch System | Using together of noise SQ, carrier SQ and tone SQ |
| Tone Frequency | 32.768 kHz |
| Indicator | Audio (6 steps), RF (6 steps), ANT A/B, Audio (peak), Battery alarm |
| Channel Check | Usable frequencies scanning |
| S/N Ratio | Over 110 dB (A-weight, unbalanced output) |
| Harmonic Distortion | Under 1% (typical) |
| Frequency Response | 100 – 15,000 Hz, ±3 dB |
| Operating Temperature | –10°C to +50°C |
| Finish | Resin, black |
| Dimensions (H x W x D) | 1.73" (44 mm) 8.27" (210 mm) × 8.07" (205.1 mm) |
| Weight | 1.54 lbs (0.70 kg) |
