Williams Sound DWS INT 4 400 RCH Digi-Wave Interpretation System
The Digi-Wave™ system is a digital spread-spectrum (DSS), simultaneous two-way wireless listening system. Using its frequency-hopping algorithm, it avoids interference and is a very secure method of communication.
The Williams Sound DWS INT 4 400 RCH Digi-Wave Interpretation System includes the DLT 400 transceiver and the DLR 400 RCH rechargeable receiver, which allows users to translate and interpret in a variety of scenarios.
- Features
Features
- Accommodates up to 14 interpreters, plus floor language
- No limit to the number of listeners
- Portable - fits in a briefcase
- Economical - saves time and money
- Specification
DLT 400 Transceiver Charging Connector USB-C Charge Time 5 hrs Battery Life Up to 14 hrs talk time per chargeCurrent consumption range: 39 mA @ idle to 94 mA w/1 Ch Tx and 3 Ch Rx Security 87 bit encryption, 87+128 bit Encryption, Secure Key Code, Lock for settings Dimensions (H x W x D) 2.43" (61.8 mm) x 4.07" (103.3 mm) x 0.44" (11.3 mm) Weight 0.18 lb (0.08 kg) Ear 022 Style Around-ear speaker Plug 3.5 mm mono Driver Size 23 mm Nominal Impedance 32Ω Frequency Response 20 - 20kHz Max Power Input 30 mW Sensitivity 118 dB @ 1kHz Cord Length 39" (990.6 mm) CCS 043 Carry Case Dimensions (H x W x D) 3" (76.2 mm) x 8" (203.2 mm) x 9.25" (234.95 mm) Weight 0.7 lb (0.32 kg) DLT 400 RCH Receiver Frequency Band 2.4 GHz (ISM band) Modulation FSK Case Material Black ABS Plastic Battery Type Lithium Polymer with smart charge built into transceiver; 1800 mAH Battery Life Up to 32 hrs per charge @ 1ch Rx Power Save Auto Sleep Mode after 5 minutes of no RF signal from compatible devices Audio Frequency Response (-3dB level) Intercom Mode: 100 - 7,200 Hz
Interpretation and other modes: 100 - 11,500 HzSNR 73 dB (A-weighted) THD 0.1% (typical) Headphone Output 3.5 mm TRRS headphone jack
25 mW, R32 ΩRange Up to 900 ft (274 m) (depending upon environmental conditions) Modulation FSK RF Sensitivity -92 dBm Temp. Range 14º to 113ºF (-10º to 45ºC) Compatible Units DLT 400, DLT 300 with some limitations Approvals FCC, Industry Canada, CE, RoHS 3, WEEE, RCM, ANATEL, KC, Giteki Dimensions (H x W x D) 2.6" (66 mm) x 4.22" (107.3 mm) x 0.5" (12.6 mm) Weight 3.3 oz (94 g) including battery - Documents
Documents
- In The Box
In The Box
- (3) DLT 400 Transceivers
- (21) DLR 400 RCH Receivers
- (3) MIC 144 Headset Microphones
- (21) EAR 022 Surround Earphones
- (2) CHG 412 PRO 12-Bay Chargers
- (2) CCS 061 GR Grey Silicone Skins
- (1) CCS 061 BK Silicone Skin
- (1) CCS 056 DW 11 System Carry Case
