The Williams Sound PLA DL210NET Digi-Loop DSP Induction Loop Amplifier continues to offer DSP audio processing with flexible, powerful software control of mixing, equalization, compression, loop phase shift and more. Its potent Class D, pulse-width amplifiers maximize efficiency, and reduce size and weight.

Description

The world’s first, network-controlled Digi-Loop induction loop amplifier from Williams Sound now features control via Creston. This next-generation Digi-Loop continues to offer DSP audio processing with flexible, powerful software control of mixing, equalization, compression, loop phase shift and more. Its potent Class D, pulse-width amplifiers maximize efficiency, and reduce size and weight. Digi-Loop’s dual-amplifier design offers impressive flexibility, with the option of a single 12A output for large perimeter loops, or dual 10A outputs for phase loop arrays. With its ability to power a loop and a speaker, Digi-Loop shines as a complete room solution.

Features
  • Crestron control
  • DSP Audio Processing
  • Digital Inputs - AES3/EBU
  • LCD Screen with Metering
  • Ethernet or RS-232 control
  • USB for firmware updates
  • Mixing, Equalization, Compression, Phase, and Frequency-Shaping
  • Power-save mode
  • Master Gain Control
  • High output current: 12/10 amps
  • Active protection against short circuits
  • XLR input configurable as microphone input or line-input, balanced or unbalanced.
  • Standard 2RU, 19” rack enclosure
  • Magnetic signal couples directly to hearing aids equipped with telecoils (T-coils)
  • Can be used with optional loop receivers
  • Suitable for set-up of high or low-overspill systems, or interleaved arrays
  • Meets ADA / ADAAG guidelines
  • Meets IEC Specification 60118-4

Specifications
Rack Mount Standard 19” Rack, 2RU
Power 100-240 VAC, 50/60 Hz, 500 Watt
Digital Input (1x XLR); AES or EBU; 44.1kHz/48kHz
Analog Line Inputs (1x RCA, L+R); -10dBV, 10kΩ input impedance
Mic/Line Inputs (2x Phoenix Terminal Block); balanced or unbalanced. Mic, +4dBu, -10dBV
Mic/Line Inputs Input impedance: 1.5kΩ Mic, 10kΩ Line
70-100v Input (1x Phoenix Terminal Block); speaker-level input, for distributed audio systems.
Line Outputs (2x Phoenix Terminal Block); loop-through of Mic/Line inputs 1 & 2
Output Power A Output only (one loop): up to 12A RMS. A and B outputs (two loops): up to 10A RMS per output
Output Power Output A can also be configured in the menu to be a speaker output; 50W @ 4Ω
Loop Resistance 0.5Ω to 1.5Ω (DC)
Loop Frequency Response 100Hz to 10kHz @400mA (Output A or B)
Speaker Frequency Response 20Hz - 20kHz (Output A)
Total Harmonic Distortion
Dynamic Range >90dB, A-weighted, typical
Front Controls Front display menu access/adjustment via control dial
Remote Control/Configuration PLA DL210: USB, RS-232 PLA DL210NET: Ethernet, USB, RS-232
Dimensions (H x W x D) 3.5" (90 mm) x 19" (482.6 mm) x 12" (304.8 mm)
Weight 14.3 lbs (6.5 kg)

In The Box
  • (1) PLA DL210NET Loop Amplifier
  • (1) WLC 004 Line Cord
