The Yamaha DBR15 achieves best-in-class SPL of up to132 dB and delivers the lowest frequency in its lineup. The DBR15 delivers outstanding performance for the main front-of-house sound for the live performance or DJ events that require highly prominent low and more power.
The most portable powered loudspeakers Yamaha has to offer, the versatile DBR Series harnesses the same state-of-the-art Yamaha DSP and amplifier and speaker technologies developed for the professional DSR Series and DXR Series lineups, ensuring high-resolution sound at any output level. Comprised of 10", 12" and 15" models, each DBR loudspeaker is housed in a newly designed, durable, lightweight cabinet optimized for FOH sound, floor-monitoring and even rigged applications. Whether you're powering your band's live performance, DJ-ing a party, or MC-ing an event, be prepared for DBR Series speakers to take your performance to the next level.
| Frequency Range (-10 dB) | 50Hz – 20kHz |
|---|---|
| Nominal Coverage | H: 90°; V:60° |
| Components - LF | Diameter: 15" cone, Voice Coil: 2.5", Magnet: Ferrite |
| Components - HF | Diaphragm: 1.4", Type: 1" throat compression driver, Magnet: Ferrite |
| Crossover | 2.1kHz: FIR-X tuning™ (linear phase FIR filter) |
| Output Power | Dynamic: 1000W (LF: 800W, HF: 200W) / Continuous: 465W (LF: 400W, HF: 65W) |
| Maximum Output Level (1m; on axis) | 132 dB SPL |
| I/O Connectors | INPUT 1: Combo x1, INPUT 2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix) |
| Processors | D-CONTOUR: FOH/MAIN, MONITOR, OFF |
| Heat Dissipation | Fan cooling, 4 speeds |
| Power Requirements | 100 V, 100-120V, 220-240 V, 110/127/220V (Brazil), 50/60Hz |
| Power Consumption | 74W (1/8 Power Consumption), 18W (Idle) |
| Cabinet Material | Plastic |
| Finish | Black |
| Flying and Mounting Hardware | Bottom x 2, Rear x 1 (Fit for M8 x 15 mm eyebolts) |
| Pole Socket | 35 mm (Bottom x 1) |
| Accessories | BBS251, BCS251, BWS251-300, BWS251-400 (Optional Speaker bracket) |
| Dimensions (H x W x D) | 27.6" (700 mm) x 17.9" (455 mm) x 14.9" (378 mm) |
| Net Weight | 42.6 lbs (19.3 kg) |
