Yamaha DHR15M 15" 1000W 2-Way Powered Loudspeaker Monitor with FIR-X Tuning

Yamaha DHR15M 15" 1000W 2-Way Powered Loudspeaker Monitor with FIR-X Tuning

More Views

Yamaha DHR15M 15" 1000W 2-Way Powered Loudspeaker Monitor with FIR-X Tuning

Part # DHR15M

Model # DHR15M

The Yamaha DHR15M powered loudspeaker features a custom Coaxial Driver design that provides near-perfect phase response, making it one of the most accurate floor monitors in its class. With 1000 Watts of Class D power, up to 131 dB SPL is posssible. A strong steel grille and rugged plywood cabinet will stand up to well to stage use.

Availability:

Qty:

Description

Details

Yamaha DHR15M 15" 1000W 2-Way Powered Loudspeaker

The DHR15M is a 2-way bi-amp powered loudspeaker featuring a 15-inch woofer and a 1.75-inch HF driver in a space-saving coaxial configuration with a custom-designed constant directivity horn, making it ideal for use as a floor monitor. Combining a 1000W amplifier and high-performance DSP with the same plywood construction found on Yamaha's high-end DZR Series, the DHR15M delivers best-in-class sound quality and durability.

The coaxial driver provides precise, smooth phase and frequency response characteristics that are especially well-suited for monitoring applications. Its plywood cabinet delivers clear sound with minimal vibration, while the compact, low-profile enclosure is coated with polyurea for a robust, scratch-resistant finish. A built-in pole socket allows for stand mounting, and Yamaha’s proprietary FIR-X™ tuning offers FIR filtering and corrective EQ to minimize phase distortion.

Features

Features

15" powered loudspeaker with 1000W of class-D power
The DHR15M delivers extremely high power from its compact, low profile enclosure
Equipped with a 1.75" HF compression driver coaxially mounted to a high-output 15" LF unit
Maximum 131 dB SPL of power and wide frequency response range of 50Hz-20kHz
Ultra-Precise 48bit DSP processing for clear high-definition sound and built-in D-Contour intelligent dynamic control
Durable polyurea coated compact plywood enclosure
35mm socket to allow placement on a stand or pole

Specification

Configuration	Active 2-Way
Total Power Capacity	465W RMS and 1000W Peak
LF Driver	1x 15" / 381 mm Woofer
HF Driver	1.75" PET
Frequency Range	50 Hz to 20 kHz -10 dB
Maximum SPL	131 dB
Coverage Angle	65° H x 75° V
Audio I/O	1x Combo speakON-1/4" 3-Pin Female Balanced/Unbalanced Mic/Line Input 1x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line Input 1x Stereo RCA TS Female Unbalanced Line Input 1x XLR 3-Pin Male Balanced Line Thru/Output
Mounting	1 x 1.4" / 35 mm Pole Socket (Bottom, Side)
Dimensions (H x W x D)	25.3" (642 mm) x 14.5" (369 mm) x 18.9" (505 mm)
Weight	50.7 lbs (23 kg)
