Yamaha VC4N 4" 2-Way Coaxial Ceiling Speaker with 160° Coverage - No Back Can, White

Part #:
VC4NW
Model #:
VC4N
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL
The Yamaha VC4N is a 4" 2-way coaxial ceiling speaker with 160° coverage and a no back can design for shallow ceilings. Ideal for BGM and voice, it supports 16-ohm and 70/100V systems and includes a paintable white magnetic grille for seamless integration.

Description

Yamaha VC4N 4-Inch 2-Way White Coaxial Ceiling Speaker

The VC4N is a compact 4-inch 2-way coaxial ceiling speaker designed to deliver clear background music and articulate voice reproduction in commercial environments. Its clean white finish blends effortlessly into modern ceilings, making it ideal for retail, hospitality, offices, classrooms, and public facilities. With wide 160° coverage, the VC4N ensures smooth, even sound across the room.

Featuring a no back can, low-profile design, the VC4N is perfect for installations where ceiling depth is limited. It supports both 16-ohm and 70/100V distributed systems, giving integrators maximum flexibility when connecting multiple speakers. The paintable white magnetic grille allows the speaker to match any decor, while durable components ensure long-lasting performance.

Whether used for ambient BGM or clear paging applications, the Yamaha VC4N offers excellent audio quality at a highly accessible price point, making it a reliable choice for professional ceiling speaker installations.

Features

  • White 4" 2-way coaxial ceiling speaker for commercial audio applications
  • No back can, low-profile white design ideal for shallow or restricted ceiling spaces
  • Wide 160° dispersion for consistent room coverage
  • Compatible with 16-ohm and 70/100V systems for versatile installation options
  • Optimized for background music and voice reproduction
  • Paintable white magnetic grille for seamless architectural integration
  • Double-threaded clamp screws for fast, secure mounting
  • Single-unit package

Specifications

System Type 2-way Coaxial type (without backcan)
LF Driver 4" Cone
HF Driver 0.8" Film dome
Frequency Range (-10 dB) 85 Hz - 20 kHz
Coverage Angle (H x V) 160° conical
Nominal Impedance 16Ω
Transformar Taps 70V: 6W, 3W, 1.5W, 0.8W
100V: 6W, 3W, 1.5W
Power Rating NOISE: 15W, PGM: 30W, MAX: 60W
Sensitivity (1W, 1m) 88 dB SPL
Maximum SPL 106 dB SPL
Connectors 1 x Push terminal (WAGO 294 /2 pin)
Material, Finish, Color VC4NW: White (approx. Munsell N9.3)
Packaging Single
Certificate CE, RoHS
Required Ceiling Board Thickness 2 mm - 37 mm
Dimensions (Dia x D) 8.86" (225 mm) x 4.06" (103 mm)
Weight 3.1 lbs (1.4 kg)
