The Yamaha VC6N is a 6.5" 2-way coaxial ceiling speaker with 120° coverage and no back can. Its low-profile white design, 16Ω/70V–100V support, and paintable magnetic grille make it ideal for BGM and voice applications in commercial spaces.

Description

Yamaha VC6N 6.5-Inch 2-Way White Coaxial Ceiling Speaker

The VC6N 6.5" ceiling speaker in white delivers premium sound quality at an affordable price for commercial installations. Engineered for clear background music and voice reproduction, its coaxial 6.5" woofer and 0.8" tweeter provide smooth, balanced audio with a wide 120° coverage angle.

Designed with a no back can, low-profile white housing, the VC6N fits easily into ceilings with limited depth, making it perfect for spaces where a back enclosure is not feasible. Its paintable magnetic grille blends seamlessly with modern interiors, providing a clean and professional finish while maintaining acoustic performance.

The VC6N supports both 16-ohm low-impedance and 70V/100V high-impedance systems, offering integrators flexible installation options for multi-speaker setups. Installation is fast and secure with double-threaded clamp screws and large non-slip mounting clamps, making the VC6N a reliable choice for offices, retail, hospitality, and educational environments.

Features

  • 6.5" 2-way coaxial ceiling speaker with 0.8" tweeter
  • Wide 120° coverage for even sound distribution
  • No back can, low-profile white design fits tight ceiling spaces
  • Supports 16Ω low-impedance and 70V/100V high-impedance systems
  • Optimized for BGM and voice reproduction
  • Paintable white magnetic grille for seamless ceiling integration
  • Double-threaded clamp screws and non-slip mounting clamps for secure installation
  • Lightweight and compact for easy installation
  • Single-unit package for flexible system design
  • Ideal for commercial, retail, office, hospitality, and education environments

Specifications

System Type 2-way Coaxial type (without backcan)
LF Driver 6.5" Cone
HF Driver 0.8" Soft dome
Frequency Range (-10 dB) 63 Hz - 20 kHz
Coverage Angle (H x V) 120° conical
Nominal Impedance 16Ω
Transformar Taps 70V: 12W, 6W, 3W, 1.5W
100V: 12W, 6W, 3W
Power Rating NOISE: 25W, PGM: 50W, MAX: 100W
Sensitivity (1W, 1m) 89 dB SPL
Maximum SPL 109 dB SPL
Connectors 1 x Push terminal (WAGO 294 /2 pin)
Material, Finish, Color VC6NW: White (approx. Munsell N9.3)
Packaging Single
Certificate CE, RoHS
Required Ceiling Board Thickness 2 mm - 37 mm
Dimensions (Dia x D) 11.26" (286 mm) x 4.49" (114 mm)
Weight 5.1 lbs (2.3 kg)
