Yorkville E15 Elite Series 15 inch Passive Loudspeaker (Discontinued)

By Yorkville

Yorkville E15 Elite Series 15 inch Passive Loudspeaker (Discontinued)

Name: Yorkville E15 Elite Series 15 inch Passive Loudspeaker (Discontinued)
Brand: Yorkville
SKU: YORK-E15

Write a Review

Part #:

E15

Model #:

E15

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Yorkville E15's extended bottom end can easily cover many club applications on its own, when used with the processor and a subwoofer, it can be the ideal mid-high loudspeaker cabinet.

Description

The E15's extended bottom end can easily cover many club applications on its own, when used with the processor and a subwoofer, it can be the ideal mid-high loudspeaker cabinet. The E15 can be utilized vertically or horizontally and comes equipped with flypoints and recessed standmount adaptor for maximum versatility.

The rotatable 80° x 50° horn means high frequency dispersion can be tailored to suit the cabinet's placement. Integrated flypoints and standmount adaptor means the E15 can be flown or stage-mounted in used as a front-of-house box or stage monitor in any installation, touring or club rig.

The unique cabinet shape makes for tighter arrays and the ability to fly the cabinet much closer to walls and ceilings than most conventional boxes. When used with the EP1215 processor, the E15 can be easily bi-amplified, or used with any élite series subwoofer.

Features

1400W Full Range Loudspeaker (700W Program)
15" Woofer / 1" Compression Driver
Max SPL Peak 133dB (130dB Continuous)
Designed for Front-of-House or Monitor applications
80° x 50° ABS Rotatable Custom Waveguide Horn
Advanced PTC™ High Frequency Driver Protection
2 x Speakon™ and 2 x 1/4" Parallel Inputs
Integrated All Metal Speaker Standmount Adaptor
5/8" (15 mm) Birch Plywood Construction

Specifications

System Type	Multi Application Loudspeaker
Active or Passive	Passive
Program Power	700W (1400W Peak / 450W Continuous)
Biampable	Yes
Nominal Impedance	8Ω
Sensitivity	100 dB @1W/1m
Max SPL	129dB
Frequency Response	55 - 26k Hz +/- 3db
Crossover Frequency	1900 Hz
Driver Configuration	15" / 1"
HF Driver(s)	1" throat (1.5" voicecoil)
HF Program Power	30W
HF Impedance	8Ω
HF Horn	ABS plastic custom Waveguide
HF Dispersion (°H x °V)	80° x 50° (Rotatable)
HF Protection	PTC
LF Driver(s)	15" (3" voicecoil)
LF Program Power	450W
LF Impedance	8Ω
Inputs - 1/4	2
Inputs - Speakon 4-pin	2
Flying Hardware	3/8" x 3 (2 Top, 1 Black)
Bar Handles	2
Pole Mount	Adapter (1 3/8" - 3.5 cm)
Enclosure Materials	15 mm (5/8") 11-ply Russian Birch
Grille	Perforated metal
Covering / Finish	Black Ozite (Carpet)
Optional Covering / Finishes	Black Ultrathane Paint (E15B)
Processor (Optional)	EP1215
Dimensions (H x W x D)	28.5" (723.9 mm) x 19" (182.6 mm) x 15" (381 mm)
Weight	54.7 lbs (24.8 kg)
