Audix W3ADX10 Wireless Bodypack System with Lavalier Microphone (Discontinued)

Part #:
W3ADX10
Model #:
W3ADX10
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Audix W3ADX10 is a RAD360 Wireless Bodypack System with ADX10 Lavalier Microphone isolates speech while minimizing unwanted room noise. Simply put, the performance of this system is robust, clear and reliable.

Description

The Audix W3ADX10 is a RAD360 Wireless System that is frequency agile with 193 selectable frequencies (per system group) and dual tuner, true diversity receivers.

The RAD360 is designed for a wide range of professional applications including live performances, fixed installations, corporate meetings, education and Houses of Worship.

The W3ADX10 wireless package features the ADX10 to isolate voice while minimizing unwanted room noise. Simply put, the performance of this system is robust, clear and reliable. The B360 body pack transmitter, constructed of durable ABS composite, is housed in a protective metal cradle. It may be used with lavalier, headset and specialty instrument microphones.

The ADX10 is a miniaturized condenser microphone designed for lavaliere applications such as speech, presentation and theatrical production. The ADX10 has the ability to accurately capture and reproduce vocals from a comfortable distance of 4"- 8". This mic is clear, resistant to feedback and easy to use. The ADX10 also includes a tie-clip and a 3' attached cable  terminating to a mini-XLRf connector.

This system is designed with a uniformly controlled cardioid polar pattern, the ADX10 helps to isolate the area or section being miked from other vocals or instruments on stage. It has a smooth, accurate frequency range of 50 Hz - 18 kHz. This mic is lightweight, low profile and has a natural sound with exceptional sound response.



Features

General:

  • Frequency agile
  • Soft-key controls
  • Backlit LCD menu driven displays
  • Noise squelch circuitry analyzes signal quality
  • Surface Acoustic Wave (S.A.W.) filters RF resistance
  • Tone key squelch eliminates unwanted noise
  • Tuned antennas
  • Audio output
  • RF level meters
  • Audio meters
  • Battery power indicators
  • Easy to use set and lock function
  • Sensitivity adjustment
  • Interchangeable head assemblies
  • Durable metal housings

ADX10 Lavalier:

  • Small, lightweight, low profile
  • Natural, accurate sound reproduction
  • Easy to use and set up
  • Field replaceable capsule

Specifications

General
Switchable Frequencies 193 (per system group of 24 MHz spaced 125 kHz apart)
Frequency Response 40 Hz–18 kHz (depending on capsule)
Signal To Noise Ratio >110 dB
Compander System HDX
Pilot Tone 32.768 kHz
RAD360 Receiver
Receiving System Dual tuners, true diversity receiver
Image Rejection 50 dB nominal, 45 dB minimum
Signal-to-Noise Ratio 110 dB @ 30 kHz deviation (IEC-weighted), max modulation 75 kHz
Total Harmonic Distortion 1% (10 kHz deviation at 1 kHz)
Sensitivity 26 dBμV (S/N 60 dB at 5 kHz deviation, IEC-weighted)
Intermediate Frequency 55.875 MHz, 10.7 MHz
Audio Output (AF Level Set At “0”) Unbalanced: 40 mV (at 1 kHz, 10kHz deviation, 10k ohm load)
Balanced: 8mV (at 1 kHz, 10kHz deviation, 600 ohm load)
Output Connectors Unbalanced: 1/4” phone jack
Balanced: XLR
Nominal Peak Deviation Balanced: -24 to +18dBu
Unbalanced: -30 to +12dBu (adjustable in 6 dB-steps)
Adjacent Channel Rejection >68 dB
Intermodulation Spacing >68 dB
Image Rejection >72 dB
Power Supply 120V AC 60 Hz; 12-18V DC, 350 mA, with external supply
Dimensions (H x W x D) 1.1" (38 mm) x 8.35" (212 mm) x 6.5" (165 mm)
Weight 2.32 lbs (1.05 kg)
B360 Bodypack
RF Power Output 50 mW Max
Spurious Emissions Under federal regulations
Input Connector 3 pin mini-XLR
Input Controls Mic/line switch, and 20 dB potentiometer
Current Consumption 100 mA typical
Input Impedance Mic: 10k Ohm; Line: 1M Ohm
Max Sound Pressure Level Approx. 128–140 dB (depending on mic)
Dimensions (H x W x D) 4" (104 mm) x 2.8" (71.3 mm) x 1" (27 mm)
Weight (with Battery) 0.450 lbs (0.204 kg)
ADX10 Lavalier Microphone
Transducer Type Pre-Polarized Condenser
Frequency Response 50 Hz - 18 kHz
Polar Pattern Cardioid
Output Impedance 800 Ohms balanced
Sensitivity 4.5 mV / Pa @ 1k
Equivalent Noise Level 25 dB (A weighted)
Signal to Noise Ratio 69 dB
Power Requirements 9 - 52 V phantom
Maximum SPL ≥120 dB
Cable / Connector Shielded 3’ terminating to a miniature 3 pin Female XLR connector
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3
Housing / Finish Brass / Black E-Coat
Dimensions (H) 0.98" (25 mm)
Weight 0.24 lbs (0.109 kg)

DOCUMENTS

In The Box

  • (1) RAD360 UHF Receiver with Antennas
  • (1) Power Supply
  • (1) B360 Body Pack Transmitter
  • (1) ADX10 Cardioid Lavalier Microphone
