Beyerdynamic MC 840 Large Diaphragm Condenser Microphone (Discontinued)

Name: Beyerdynamic MC 840 Large Diaphragm Condenser Microphone (Discontinued)
Brand: Beyerdynamic
SKU: BEYER-482838
Price: 1599.99 USD
Availability: OutOfStock

Write a Review

Part #:

482838

Model #:

MC 840

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Beyerdynamic MC 840 is a very compact large diaphragm studio microphone with a gold vaporised double diaphragm and 5 selectable polar patterns (omnidirectional, wide cardioid, cardioid, hypercardioid,).

Description

On the basis of the MC 740 microphone capsule this new microphone has been equipped with an improved low-noise pre-amplifier and an impedance transformer without transducer. Due to a two-stage roll-off filter (80 and 160 Hz) compensating the close miking effect and a two-stage pre-attenuation (-10 and -20 dB) the MC 840 is a superior microphone for any recording application. It has been designed without compromise to capture every sound detail with absolute clarity and purity. Applications for the MC 840 include recording orchestras resulting in a superb transparent sound.

Features

Large diaphragm capsule with gold vaporised double diaphragms.
Elastic capsule mounting.
Five selectable polar patterns.
Switchable pre-attenuation for high sound pressure levels.
Switchable two-stage roll-off filter.

Specifications

Transducer type	Condenser
Operating principle	Pressure gradient
Frequency response	30 - 20,000 Hz
Polar pattern	switchable:Omnidirectional,Wide cardioid,Cardioid,Hypercardioid,Figure eight
Open circuit voltageat 1 kHz (0 dB = 1 V/Pa)	18 mV/Pa
Nominal impedance	180 Ω
Load impedance	1000 Ω
Max. SPL at 1 kHz,without pre-attenuation	127 dB
With -10 dB pre-attenuation	137 dB
With -20 dB pre-attenuation	147 dB
Signal-to-noise ratio rel. to 1 Pa	Approx. 70 dB
A-weighted equivalent SPL	Approx. 17 dB
Power supply	11 - 52 V phantompower
Current consumption	4.6 mA
Low frequency roll-off	Switchable, 6 dB/octaveat 80 Hz and 160 Hz
Connector	3-pin XLR malePin 1 = ground,Pin 2 = +, Pin 3 = -
Dimensions	Specifications
Length	165 mm
Shaft diameter	37 mm
Head diameter (L x W x H)	70 x 52 x 33 mm
Weight	0.630 lbs (286 g)
