Bose Professional RoomMatch Utility RMU206 Dual 6.5" Small-Format Under-Balcony Fill Loudspeaker - White (Discontinued)

Name: Bose Professional RoomMatch Utility RMU206 Dual 6.5" Small-Format Under-Balcony Fill Loudspeaker - White (Discontinued)
Brand: Bose Professional
SKU: BOSE-638392-0210

Write a Review

Part #:

638392-0210

Model #:

RoomMatch Utility RMU206

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

Bose RoomMatch Utility RMU206 Small-Format Under-Balcony Fill Loudspeaker
Minimal Height for Under-Balcony or Low-Ceiling Mounting

The Bose RoomMatch Utility RMU206 small-format under-balcony fill loudspeaker features a unique angled baffle enclosure design to minimize the projected height for typical under-balcony and low-ceiling zone-fill applications. The design also features a single Bose® EMB2 compression driver to provide mid/high frequency voicing similar to that of RoomMatch full-range array modules and all RoomMatch Utility models. Two 6.5-inch woofers provide vocal-range output and a rotatable high-frequency waveguide increases mounting flexibility.

Applications:

Under-balcony and zone fill
High-quality foreground music
Stage-front fill

Features

Award-winning RoomMatch sound – now in smaller, 2-way, point-source designs for high-level foreground music, under-balcony, and zone-fill applications
Bose EMB2 compression driver – for lower distortion and improved vocal clarity compared to conventional foreground/fill models; also provides consistent mid/high sonic character to that of RoomMatch full-range and other RoomMatch Utility models
Minimal height for under-balcony or low-ceiling mounting – unique enclosure baffle design provides minimum projected height for under-balcony or low-ceiling mounted applications
120° x 60° constant-directivity high-frequency horn – gives wide, even coverage and may be rotated in enclosure. Can reduce the number of speakers required for under-balcony applications
2 x Bose LF6 6.5-inch woofers – with extended-excursion voice coils extend response to 80 Hz for lowest vocal range
Quasi-3-way passive crossover with separate filters for each transducer – provides more consistent frequency and polar response compared to conventional crossover designs
80 Hz – 16 kHz frequency response and 122 dB maximum peak SPL – deliver the performance required for most demanding under-balcony and zone-fill applications
Flexible mounting with included U-bracket – rear enclosure panel also includes 4 x M8 threaded inserts in 5.0” x 2.75” (127mm x 70mm) pattern to accept third-party accessory mounting brackets

Specifications

System Performance
Frequency Response (+/-3 dB)	90 Hz - 16000 kHz
Frequency Range (-10 dB)	80 - 18000 Hz
Recommended High-Pass Protection Filter	80 Hz with minimum 12-dB / octave filter
Nominal Coverage Pattern (H x V)	120° H x 60° V (rotatable high-frequency horn)
Crossover Type	Passive; separate bandpass filters per transducer (300 Hz and 1.5 kHz)
Power Handling (Long-Term Continuous)	Bose extended-lifecycle test: 250W AES transducer test: 300W
Power Handling (Peak)	Bose extended-lifecycle test: 1000W AES transducer test: 1200W
Sensitivity (SPL / 1 W @ 1 m)	Bose extended-lifecycle test (Free Field): 90 dB Bose extended-lifecycle test (Wall/Ceiling): 92 dB AES transducer test (Free Field): 90 dB AES transducer test (Wall/Ceiling): 92 dB
Calculated Maximum SPL @ 1 m	Bose extended-lifecycle test (Free Field): 114 dB Bose extended-lifecycle test (Wall/Ceiling): 116 dB AES transducer test (Free Field): 115 dB AES transducer test (Wall/Ceiling): 117 dB
Calculated Maximum SPL @ 1 m (Peak)	Bose extended-lifecycle test (Free Field): 120 dB Bose extended-lifecycle test (Wall/Ceiling): 122 dB AES transducer test (Free Field): 121 dB AES transducer test (Wall/Ceiling): 123 dB
Transducers
Low Frequency	2 x Bose LF6 high-excursion 6.5-inch woofers (1.5-inch voice coil)
High Frequency	1 x Bose EMB2 extended-midband high-frequency compression driver (2-inch voice coil)
Nominal Impedance	8 ohms
Physical
Enclosure Material	13 mm Birch plywood
Finish	Two-part spray polyurethane coating, white
Grille	18-gauge (1.2 mm) perforated steel, powder-coated finish, white
Environmental	Indoor use only
Connectors	2 x Neutrik® NL4 and 1 x barrier strip, wired parallel
Suspension / Mounting	2 x M8 threaded inserts (1 each side) for U-bracket 4 x M8 threaded inserts on rear surface (127 x 70 mm, 4-bolt pattern)
Dimensions (H x W x D)	7.5" (191 mm) x 21.8" (552 mm) x 9.5" (241 mm)
Weight	25 lbs (11.3 kg)
Weight (with U-bracket)	29 lbs (13.2 kg)
Shipping Weight	33 lbs (15 kg)
