The Vocalist Live Pro is a rack processor based on the Vocalist Live™ 4 that includes a new MIDI interface that works with keyboards as well as guitars.

Description

The Vocalist Live Pro is a rack processor based on the Vocalist Live™ 4 that includes a new MIDI interface that works with keyboards as well as guitars. Utilizing the patent-pending musIQ™ - technology combining new Note Detection algorithms with state-of-the-art Harmony Generation - and the raw power of AudioDNA2, the Vocalist Live Pro can create real-time harmonies with your live voice that are in key and perfectly on pitch. With all that processing power, we were able to pack it full of other features as well, including world-class Lexicon® Reverbs, Soundcraft® low-noise studio-grade mic preamp, real-time pitch correction for each voice, individual persona and gender selection per voice, configurable outputs, tuner, 99 user factory presets and more. Plus, it's available with a fully assignable optional foot switch and expression pedal so you get real-time control and kick in the harmonies at just the right moment.

Features

3 or 4 part vocal harmony using the musIQ technology with MIDI that analyzes the guitar and keyboard signal according to chord recognition.
Selectable unison, 3rd, 5th or octave above or below of lead vocal.
Pitch correction for each individual voice with 4 adjustable parameters.
Lead vocal and harmony effects; Compressor, Lexicon Licensed Reverbs and EQ, Persona models.
Edit, store and recall 99 user or 99 factory presets.
On board guitar tuner.
XLR mic /line w/ level adjustment, Soundcraft studio grade preamp and 48V phantom power.
L/R Stereo ¼" aux outputs, L/R XLR main outputs, S/PDIF out, ground lift, selectable output routings.
MIDI in/thru.
USB for preset Librarian and exchange.
Footswitch and expression pedal jacks for remote control of presets and effects.

Specifications

Mic Preamp Connector	XLR balanced
Mic Preamp Input Sensitivity	for 0dBFS: -31.5dBu to +10dBu, for Analog Clip: -15.5dBu to +20dBu
Mic Preamp Equivalent Input Noise (EIN)	-126.5 dBu A-Weighted, Ref 150 Ohms
Mic Preamp Input Impedance	2.4KOhms Balanced
Mic Preamp Thru	XLR Male (Direct Connect to Mic In)
Line Input Connector	1/4" Balanced/Unbalanced TRS Connectors
Line Input Sensitivity	for 0dBFS: +4.5dBu to +21dBu
Line Input Impedance	10K Ohms Balanced, 5K Ohms Unbalanced
Dynamic Range	107dB A-weighted
THD	0.002% (1KHz, Gain Max, 0dBu Input)
Frequency Response	-3dB at 25Hz and 22KHz
Guitar Input/Thru Connectors	1/4" Unbalanced TS Connectors
Guitar Input/Thru Max input level	6 Vpp
Guitar Input/Thru Impedance	Ground Connected: 2.2M Ohms, Ground Lifted: 4.4M Ohms
A/D Converter	24 bits/44.1kHz
D/A Converter	24 bits/44.1kHz
Digital Output	S/PDIF: RCA Connector. Sample Rate Reflects Internal Sample Rate of D/A Converters
USB Type	B Port USB 1.1 Compliant, USB Full-Speed Mode (12Mbps) Class compliant MIDI port
MIDI	IN, THRU
Power Supply	220-240 VAC 50/60Hz / 100VAC, 50-60Hz / 120VAC, 60Hz
Power Consumption	17 Watts
Operating Temperature	60-95 Degrees F (15-35 Degrees C)
Dimensions	19" x 7.5" x 1.75" (217mm x 135mm x 43.5mm) (1U 19" Rackmount)
Unit Weight	6.5 lbs (3kg)
