The TX1152 15 inch loudspeaker is a high power, high sensitivity, 2-way loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in a lightweight package. The TX1152 utilizes the DH3, a high output 1.25" titanium compression driver, coupled to a Constant Directivity™ 60° x 40° horn. This combination results in a smooth response to 20 kHz and excellent pattern control in medium throw applications.
The SMX2151 15" woofer has an FEA optimized magnet structure and a shorting ring for ultra low distortion and maximum intelligibility at high SPL levels. The crossover uses steep 24 dB/octave slopes with equalization for very smooth response in vocal range, extended HF, and a protection circuit for long term reliability.
The TX1152 has a variety of features that make it equally suited for portable or fixed installation applications. The trapezoidal enclosure is constructed out of a combination of plywood and MDF, and coated with EVCoatTM for maximum strength while still remaining lightweight. The unique grille design is very strong, dent resistant, and features a rotatable logo. Four way handles allow for gripping the TX1152 in a variety of positions, a pole mount allows for placement on a subwoofer or a tripod. Six 3/8" threaded points allow a single TX1152 to be suspended in a various positions. The recessed input panel with dual NL4 connectors panel keeps the connectors hidden while allowing the TX1152 to be used with the TX1181 subwoofer for extended sub bass on a single amplifier channel, with no additional processing needed.
| Frequency Response (-3 dB) | 55 Hz - 20 kHz |
|---|---|
| Frequency Range (-10 dB) | 40 Hz - 20 kHz |
| Rec. Hipass Frequency | 40 Hz |
| Axial Sensitivity | 100 dB (1W/1m) |
| Max. Calculated SPL | 133 dB |
| Horizontal Coverage | 60°, or 40° |
| Vertical Coverage | 40°, or 60° |
| Power Handling | 500W Continuous, 2000W Peak |
| LF Transducer | SMX2151, 15 in (381 mm) Driver |
| HF Transducer | DH3, 1.25 in (32 mm) Diaphragm Compression Driver |
| Crossover Frequency | 1650 Hz |
| Nominal Impedance | 8 Ohms |
| Minimum Impedance | 5.6 Ohms |
| Connectors | (2) Neutrik Speakon NL4’s |
| Enclosure Material | Plywood and MDF with EVCoatTM |
| Grille | 16 GA Steel, Black Powdercoat, with Rotatable Logo |
| Suspension | (6) 3/8" Threaded Points - (2) on Each Side and (2) on the Rear of Enclosure |
| Dimensions (H x W x D) | 30.6" (776 mm) x 17.5" (446 mm) x 17.5" (446 mm) |
| Weight | 61.2 lbs (27.8 kg) |
| Shipping Weight | 68.7 lbs (31.2 kg) |
