Fostex PX-5 5.2 inch 2 Way Monitor Speaker - Pair (Discontinued)

Fostex PX-5 5.2 inch 2 Way Monitor Speaker - Pair (Discontinued)

Name: Fostex PX-5 5.2 inch 2 Way Monitor Speaker - Pair (Discontinued)
Brand: Fostex
SKU: AMX-FOSTEX-PX5
Price: 499 USD
Availability: OutOfStock

Write a Review

Part #:

PX-5

Model #:

PX-5

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Fostex PX-5 Professional Monitor Speaker consists of totally new 5.2-inch LF driver and 1-inch HF tweeters. The superior digital FIR filter realizes unprecedented accurate sound reproduction and delivers class leading sonic performance.

Description

The PX-5 Professional Monitor Speaker consists of totally new 5.2-inch LF driver and 1-inch HF tweeters. The superior digital FIR filter realizes unprecedented accurate sound reproduction and delivers class leading sonic performance.

Features

Drivers driven by a 35W (LF) / 18W (HF) digital amplifier.
5.2-inch Crimson woofer constructed of aramid fiber with mixed diaphragm impregnated with resin to enhance fiber bonding for higher rigidity.
1-inch Urethane film laminated polyerster fiber dome tweeter tuned with the back chamber for smooth high frequency sonics.
Digital Network Filter (FIR type) for dividing network - results in very accurate time alignment to deliver supreme sound positioning.
Unique Rotary Encoder plus LED indication with no aging quality deterioration.
44 step level control by Volume/Trim adjustments.
+/-3dB per 0.3dB step HF level control and +/- 20 step LF roll off frequency adjustment.
Auto Standby / Auto Operation function for electric power saving.
Fade In function to gradually increase the output level when powering on.

Specifications

Enclosure type	2 way bass reflexUnits
Tweeter	1-inch soft dome tweeter
Woofer	5.2-inch Aramid fiber diaphragm
Frequency Response	50 Hz – 20k Hz
Rated Output Power Low	35W High: 18W
Inputs	XLR-3-31 connector (balanced)
Maximum input level	+24 dBu
Input Impedance	20k ohm or more 1/4-inch Phone jack (unbalanced)
Maximum input level	+10 dBV
Input Impedance	10k ohm or more RCA jack (unbalanced)
Maximum input level	+10 dBV
Input Impedance	10k ohm or more
S/N Ratio	86 dB
Distortion (T.H.D.)	0.1%
Crossover Frequency	2.5 kHz
Subsonic filter	50 Hz
Power Requirement	120 VAC, 60Hz
Power Consumption	50 W (0.5W or less in standby mode)
Dimensions (H x W x D)	11" (280 mm) x 7.09" (180 mm) x 8.27" (210 mm)
Weight	11.02 lbs (5 kgs)
