Harman Kardon AVR 1510S 5.1 Channel AV Receiver

Home /
Harman Kardon AVR 1510S 5.1 Channel AV Receiver (Discontinued)

Description

Details

This 375-watt, high-performance, 5.1-channel A/V receiver makes your music, movies and shows sound better than ever. Whether it’s your Blu-ray™ player, HD cable set-top box or game console, you want the best picture quality and sound. And you need one simple way to connect them all. The Harman Kardon® AVR 1510S is a 5.1-channel, networked audio/video receiver that provides you with four 3D-ready HDMI® inputs with 4K pass-through. Plug them in once, and you’re all set. With built-in Spotify Connect feature, you can stream directly Music from your Spotify premium account on your phone, tablet or computer on the same network, and built-in vTuner™ Internet radio connects you to a whole world of online audio entertainment. Versatile and muscular, the AVR 1510S can pump out up to 375 watts; with it, you’ll hear powerful audio with all the clarity you’ve come to love from Harman Kardon products. The receiver is lighter, too, thanks to HARMAN GreenEdge™ certification. You’ll experience serious power, only now in an environmentally friendly form factor. And if you’re one of those who enjoy even more control, the Harman Kardon Remote app is available for download – giving you the freedom to control your home theater experience from the comfort of your own device. Sleek, light and powerful, the Harman Kardon AVR 1510S is the perfect balance between versatility and beautiful sound.

Features

Features

Five 75W-per-channel amplifiers with high-performance digital power supply
Spotify Connect
Built-in vTuner Internet radio
Four 3D-ready HDMI inputs
Front-panel USB port for connection to compatible Apple products or USB sticks
Dolby® TrueHD and DTS-HD Master Audio™ decoding
HARMAN GreenEdge certification
Compact design
Colour-coded connectors and binding-post speaker terminals
Multidevice, programmable remote control

Specification

Audio Section
Stereo and Multichannel Power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.9% THD
Input Sensitivity/Impedance	250mV/27k ohms
Signal-to-Noise Ratio (IHF-A)	100dB
Surround System Adjacent Channel Separation	Dolby Pro Logic/DPLII: 40dB Dolby Digital: 55dB DTS: 55dB
Frequency Response (@ 1W)	10Hz – 130kHz (+0dB/–3dB)
High Instantaneous Current Capability (HCC)	±28 amps
Transient Intermodulation Distortion (TIM)	Unmeasurable
Slew Rate	40V/µsec
FM Tuner Section
Frequency Range	87.5MHz – 108.0MHz
Usable Sensitivity IHF	1.3µV/13.2dBf
Signal-to-Noise Ratio (Mono/Stereo)	70dB/68dB
Distortion (Mono/Stereo)	0.2%/0.3%
Stereo Separation	40dB @ 1kHz
Selectivity (±400kHz)	70dB
Image Rejection	80dB
IF Rejection	80dB
AM Tuner Section
Frequency Range	520 – 1710kHz
Signal-to-Noise Ratio	38dB
Usable Sensitivity (Loop)	500µV
Distortion (1kHz, 50% mod)	1.0%
Selectivity (±10kHz)	30dB
Video Section
Television Format	NTSC
Input Level/Impedance	1Vp-p/75 ohms
Output Level/Impedance	1Vp-p/75 ohms
Video Frequency Response (Composite Video)	10Hz – 8MHz (–3dB)
HDMI	HDMI 1.4
General Specifications
Power Requirement	120V AC/60Hz
Power Consumption	<0.5W (standby); 410W maximum
Dimensions (H x W x D)	4.75" (121 mm) x 17.31" (440 mm) x 11.19" (300 mm)
Weight	10 lbs (4.6 kg)
