The Control 45C/T is the smallest full-range Control 40 Series model, featuring wide bandwidth and smooth frequency response with a wide, even 120° of coverage, eliminating hot spots that traditional in-ceiling co-ax speakers can cause, and allowing fewer speakers to cover a large space. The Control 45C/T is ideal for a wide variety of applications where a smaller size, smooth response, and even coverage are desired.
Suitable for use in air handling spaces per UL1480 Speakers for Fire Alarm, Emergency and Commercial and Professional Use, complies with UL-2043 Fire Tests for Heat and Visible Smoke Release for Discrete Products, CUL, NFPA-70, NFPA- 90A Installation of Air Conditioning and Ventilation Systems. In accordance with the requirements of IEC60849/EN60849.
| Frequency Range (-10 dB) | 55 Hz - 20 kHz |
|---|---|
| Frequency Response (± 3 dB) | 80 Hz - 17 kHz |
| Power Capacity | 150 Watts Continuous Program Power 75 Watts Continuous Pink Noise |
| Nominal Sensitivity (2.83V/1m) | 88 dB |
| Nominal Coverage Angle | 120° conical coverage |
| Directivity Factor (Q) | 5.6 |
| Directivity Index (DI) | 7.3 dB |
| Rated Maximum SPL | 107 dB @ 1 m (3.3 ft) average, 113 dB peak |
| Rated Impedance | 8Ω (in bypass mode) |
| Transformer Taps | 60W 30W, 15W, (& 7.5W @ 70V) |
| Driver (LF) | 5.25" (130 mm) polypropylene-coated paper cone with butyl rubber surround 1" (25 mm) copper voice coil, vented fiberglass resin voice coil former |
| Driver (HF) | 0.75" (20 mm) soft-dome, neodymium magnet assembly, ferro-fluid cooling, aluminum voice coil former. |
| Input Connectors | Two removeable locking 2-pin connectors with screw-down terminals. |
| Knockouts | Two (top and side) |
| Cutout Size | 8.75" (220 mm) |
| Ceiling Thickness Range | Accommodates tiles/drywall up to 2.75" (70 mm) thick |
| Dimensions (D x Dia) | 9.4" (239 mm) x 9.9" (250 mm) |
| Net Weight (ea) | 8.6 lbs (3.9 kg) |
| Shipping Weight (pair) | 19 lbs (8.6 kg) |
