Line 6 XD-V55L Digital Wireless System with Bodypack Transmitter and Lavalier Microphone (Discontinued)

By Line 6

Line 6 XD-V55L Digital Wireless System with Bodypack Transmitter and Lavalier Microphone (Discontinued)

Name: Line 6 XD-V55L Digital Wireless System with Bodypack Transmitter and Lavalier Microphone (Discontinued)
Brand: Line 6
SKU: LINE6-991230125
Price: 449.99 USD
Availability: OutOfStock

Write a Review

Part #:

122121

Model #:

XD-V55L

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Line 6 XD-V55L Digital Wireless System with Bodypack Transmitter and Lavalier Microphone sets a new standard in professional wireless systems for vocalists, active performers and spoken word presenters.

Description

The XD-V55L lavalier systems give you the flexibility to choose from two vocal models and one instrument EQ filter model, enabling you to optimize the sound of the system for your voice or instrument—and deliver your performance with maximum clarity and impact.

All 12-channel XD-V55 series systems feature patented, fourth generation Line 6 digital wireless technology, which enables full-range 10Hz–20kHz (-2.5dB) frequency response, wide dynamic range up to 117dBA, and Digital Channel Lock (DCL™) technology that prevents reception of audio interference from other 2.4GHz devices and ensures signal integrity.

Ensuring peace of mind and the most reliable operation, XD-V55 systems operate in the 2.4GHz ISM band, which is free from interference due to TV broadcasts, white space devices, cell phone towers and other transmitting devices. The systems are fully FCC compliant and operate license-free worldwide, from Hollywood to Tokyo.

Features

Line 6 XD-V55 Digital Wireless System:

300-Foot Extended Range
12 Channels – Use Up To 12 Systems Simultaneously
Patented, 4th-Generation Digital Wireless Technology

XD-V55 Receiver:

Three 5-Segment LEDs For Monitoring RF Strength, Battery Status, And Audio Levels At All Times
Robust Aluminum Chassis
Dynamic Filter To Combat Unwanted Environment Noise
2 BNC Antenna Inputs For Antenna Connection

Lavalier Microphone:

Premium Cardioid Condenser Lavalier Microphone
Discreet Clothing Attachment

TBP12 Bodypack Transmitter:

Robust Metal Body
Standard TA4 Mini-XLR Input For Integrating Third-Party Microphones
LCD Display For Selecting Channels, Battery Status, EQ Filter and More
Lock Mode To Prevent Changes During Performance

Specifications

System
Frequency Band	2.4GHz ISM Band
Compatible Channels	12
Spatial Diversity with Digital Buffering	Yes
Frequency Diversity	Yes (2 Frequencies per channel)
Compander-Free Design	Yes
Frequency Response THD %	10 Hz (-0.5 dB) - 20kHz (-2.5 dB) 0.03% typical
System Latency	< 2.9 ms (audio input to output)
Operating Temp Range	0 – 50 degrees C
Receiver
RF Performance Monitoring	Yes (via LCD screen and LED)
RF Signal Strength Indicators	5-Segment LED
Audio Level Meter (on Receiver)	5-Segment LED
Dynamic Filter	Yes
Squelch & Pad Adjustments	None required
Number of Receiver Antennas	2
Receiver Format	1/2 RU (with included rack-mount kit)
Receiver Power Requirements	9Vdc 500mA
Output Impedance	XLR: 150 Ohms Balanced 1/4": 1 kOhm Unbalanced
Sensitivity	-95 dBm
Image Rejection	56 dB
Antenna Distribution	A and B
Antenna Impedance	50 Ohms
Transmitter
Transmitter RF Output Power	10 mW
Battery Life	8 hours
Mic Modeling	Yes (3 selectable EQ filters)
Batteries	2 x AA Alkaline
Battery Display (on Transmitter)	LCD Screen
Dynamic Range	>117 dB
Maximum Audio Input Level	6.5 Vpp
Beltpack Input Impedance	1.3 M Ohms
Beltpack Supplied Bias Voltage	5 VDC (on Pin 2 of TA4F Connector)
