Listen Tech D10-1-Dante D Series 10 Amp Single Loop Driver with Dante (Discontinued)

The driver features capacitive touch front panels with intuitive menus, built-in test signals, and are fully networkable with a Wi-Fi accessible standard browser-based control panel for remote set-up, monitoring, and email alerts.

The D10-1 features a 10 Amp loop output plus ample voltage headroom, making it the most flexible solution on the market, suitable for a huge range of applications. The added power of the D10-1 provides a solution for installations in environments containing very high levels of metal, previously not possible without the use of combiners.

In another first for high-power Class D Induction Loop drivers, installation can be performed with total confidence, as unique multi-stage filtering ensures compatibility with both other system equipment and global EMC regulations.

• Dante Input for Additional Network Audio
• Drives 1 output channels at 10ARMS
• Networkable with remote browser interface
• Digital display and intuitive 'touch' menu system
• 3 modes; Main, Status and Quick
• Highly energy efficient Class-D amplifier with low heat dissipation
• Up to 1,450m2 Perimeter Loops area coverage
• Compact 1U rack-mount unit with internal transformer for simple rack installation
• Optimized for speech frequencies with unmatched intelligibility and capable of high-quality musical reproduction
• AGC and Dual Slope MLC
• Active status monitoring and remote fault reporting via email
• Data compliant with: IEC 62489-1 Standard

Spec Sheet

Manual

• (1) D10-1-Dante D Series Loop Driver (10 Amps x 1) - Dante
• (1) 1U 19" Rack Mount (Brackets Included)
• (1) Handbook and Installation Instructions
• (1) T-Coil Loop System Present Sign (Deaf Logo)
• (1) Neutrik NL4 Output Connector
• (1) Region-Specific IEC Power Cable
• (1) Status and DC Connectors
