The Mackie HD1501 15" Powered Subwoofer delivers 1200W of intense low end to any Mackie system. Compact, all-wood and lightweight, this subwoofer is punchy, powerful and portable.

Description

The Mackie HD1501 15-inch powered subwoofer provides intense low-frequency extension and punch to any Mackie full-range system.

The ultra-portable HD1501 High-Definition Powered Subwoofer delivers 1200W of peak system power via Class-D Fast Recovery™ amplification. Class-D amp design delivers up to 95% efficiency and, along with the lightweight switch-mode power supply, drastically reduces this subwoofer’s weight.

EAW custom-designed HD Series transducers maximize efficiency and performance when matched with the system’s internal amp. The 15-inch woofer uses a ferrite magnet with a 3-inch voice coil.

Premium circuitry includes a symmetrical Linkwitz-Riley crossover, precision tuning filters and user-friendly features such as high pass outputs for stereo operation with a single sub.

The lightweight and portable 15mm birch plywood enclosures feature a ported, direct-radiating design. The professional look of the HD1501 may be further enhanced by defeating the front panel LED. The integrated pole-cup accommodates a standard mounting pole. Pair the HD1501 with any Mackie full-range loudspeaker for an extremely powerful and fully high-definition PA solution.

Features

1200W of ultra-efficient Class-D Fast Recovery™ amplification
600W RMS / 1200W peak power
128 dB SPL max output (peak @ 1m)
36 Hz - 145 Hz operating range
15" high-output woofer with 3" voice coil
Active electronics provide complete system optimization
Symmetrical Linkwitz-Riley crossover (100 Hz, 24 dB/octave)
Precision tuning filters for ultra-accurate bass reproduction
Phase alignment to perfectly complement Mackie full-range loudspeakers
Ported, direct-radiating design for maximum punch and low-frequency extension
Designed and tuned by Eastern Acoustic Works
Dual XLR inputs, full-range and high-pass outputs for mono or stereo setups
Level control and polarity invert switch with LED indicator
Signal / limit and thermal LED indicators
Integrated protection and limiting circuitry
Rugged all-wood cabinet (15 mm birch plywood)
Pole mount receptacle for mounting full-range speaker
Compact and lightweight (80 lbs/36.3 kg)

Specifications

Acoustic Performance
Frequency Response (–3 dB)	43 Hz – 92 Hz
Frequency Response (–10 dB)	36 Hz – 145 Hz
Max peak SPL (Calculated)	131 dB
Max peak SPL (Measured)	126 dB
Transducer
Diameter	15" (381 mm)
Voice Coil Diameter	3" (76 mm)
Diaphragm Material	Paper
Magnet Material	Ferrite
Power Amplifier
Rated Power	600W RMS 1200W Peak
THD	< 0.03%
Design	Class D
Cooling	Active, twin thermally controlled vari-speed fans
Input/Output
Input Type	Female XLR Balanced differential (stereo left/right)
Input Impedance	20k Ohms
Full Range Output	Male XLR Balanced (parallel with input)
High Pass Output	Male XLR Balanced
Output Impedance	300 Ohms
Level Control	–6 dB to +6 dB
Electronic Crossover
Crossover Type	24 dB/oct. Symmetrical Linkwitz-Riley
Crossover Frequency	100 Hz
Protection Features
Over-excursion Protection	45 Hz 24 dB/oct. Butterworth High Pass Filter
Thermal Protection	Amplifier mute, autoreset, twin thermally controlled vari-speed fans
Driver Protection	Peak/RMS Limiter
Display LEDs	Power Light ON, Polarity, Invert, Thermal, Sig/Limit, Front PowerON
AC Power Requirements	100-120 VAC, 50-60 Hz, 300W
Construction Features
Basic Design	Rectangular
Material	15 mm exterior grade premium birch plywood
Finish	High durability black paint
Handles	One on each side
Grille	Powder-coated galvanized steel
Dimensions (H x W x D)
Product	20" (508 mm) x 18.25" (464 mm) x 25" (635 mm)
Shipping	21.7" (551 mm) x 23.2" (589 mm) x 29.9" (759 mm)
Weight
Net	80 lbs (36.4 kg)
Shipping	88 lbs (39.9 kg)
