Marine Grade Sound System for Boats and Ships with 10 Weatherproof Speakers and Paging Microphone

Inside the Design

This marine grade sound system is engineered for demanding outdoor and marine environments where durability and audio clarity are essential. Featuring ten One Systems direct weather loudspeakers, this system provides consistent, high-fidelity sound coverage while withstanding exposure to moisture, salt air, and extreme weather conditions. Ideal for large boats, ships, marinas, and waterfront venues, this system delivers reliable background music and paging throughout open-air spaces.

At the heart of the system is the AtlasIED AA400PHD 400W mixer amplifier, providing ample power and flexible input options for music playback and paging. Wireless streaming is handled by the Sonos Port, offering seamless integration with modern streaming services and intuitive control from mobile devices. An Astatic 878HL-2 desktop microphone completes the system, ensuring clear and intelligible paging communication for crew and guests.

Sound System Features:

• Direct weather loudspeakers designed for long-term marine and outdoor use
• Clear, high-quality background music and paging across large open-air areas
• 400W commercial-grade mixer amplifier with multiple input options
• Wireless audio streaming via Sonos Port for modern music control
• Desktop paging microphone for reliable voice communication

About the System Components

One Systems 106.STH Direct Weather Loudspeakers

The One Systems 106.STH loudspeakers are 2-way, 6.5" direct weather loudspeakers specifically engineered for harsh outdoor and marine environments. Built with rugged, weather-resistant materials, these speakers deliver excellent sound quality while standing up to moisture, salt exposure, and temperature extremes, making them ideal for ships, marinas, and coastal installations.

AtlasIED AA400PHD 6-Input 400W Mixer Amplifier

The AtlasIED AA400PHD is a powerful 6-input, 400W mixer amplifier designed for commercial and marine audio systems. It provides reliable amplification, multiple microphone and line-level inputs, and paging functionality with Music on Hold capability, ensuring dependable performance in demanding environments.

Sonos Port Wireless Streaming Component

The Sonos Port enables seamless wireless music streaming and system integration for professional audio applications. Designed to connect to amplifiers and receivers, it provides access to popular streaming services. It allows intuitive control from mobile devices, making it easy to manage background music throughout the vessel.

Astatic 878HL-2 Omnidirectional Dynamic Desktop Microphone

The Astatic 878HL-2 is a durable omnidirectional dynamic desktop microphone designed for paging and announcements. Its clear voice reproduction and push-to-talk functionality make it well-suited for marine and commercial environments where reliable communication is essential.

One Systems 106.STH 2-Way 6.5" Direct Weather Loudspeakers

• Designed for direct weather and marine-grade outdoor applications
• Stainless steel rigging points for corrosion resistance
• Dual-layer zinc-rich powder-coated grille and included U-bracket
• Selectable 70.7V / 100V / 8-ohm operation for system flexibility
• 80W continuous power handling in 8-ohm mode
• IEC 529 IP56-rated ingress protection for harsh environments

AtlasIED AA400PHD 6-Input 400W Mixer Amplifier

• 400W output supporting 25V, 70.7V, and 4-ohm speaker systems
• Four balanced mic/line/telephone inputs with phantom power
• Automated Push Here Diagnostic® system for easy troubleshooting
• Assignable Zone 2 output and remote level control capability
• Contact closure mute terminals and variable mute sensitivity
• Rack-mountable design for professional installations

Sonos Port Wireless Streaming Component

• Wireless music streaming for integration with professional audio systems
• Connects easily to amplifiers and mixers for background music playback
• Supports multi-room audio control through the Sonos ecosystem
• Simple setup with intuitive app-based control
• Automatic software updates ensure long-term performance

Astatic 878HL-2 Omnidirectional Dynamic Desktop Microphone

• Omnidirectional pickup pattern for clear paging announcements
• Push-to-talk microphone with locking switch
• Selectable high or low impedance output
• External contact closure for paging system integration
• Durable desktop design for commercial and marine use

• (10) One Systems 106.STH 2-Way 6.5" Direct Weather Loudspeakers
• (1) AtlasIED AA400PHD 6-Input 400W Mixer Amplifier
• (1) Sonos Port Wireless Streaming Component for Stereo or Receiver
• (1) Astatic 878HL-2 Omnidirectional Dynamic Desktop Microphone
• (1000') West Penn AQ226 14/2 Aquaseal Fire-Alarm Speaker Wire - Black
