QSC AD-S282HT AcousticDesign 8 inch 2 Way Wall Mount Loudspeaker (Discontinued)

By QSC Audio

QSC AD-S282HT AcousticDesign 8 inch 2 Way Wall Mount Loudspeaker (Discontinued)

Name: QSC AD-S282HT AcousticDesign 8 inch 2 Way Wall Mount Loudspeaker (Discontinued)
Brand: QSC Audio
SKU: QSC-AD-S282HT
Price: 1000 USD
Availability: OutOfStock

Write a Review

Part #:

AD-S282HT

Model #:

AD-S282HT

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The QSC AD-S282HT is a full range, surface mount loudspeaker with a sleek, contemporary styling that fits perfectly into multiple surroundings and applications including hotels, restaurants, and convention facilities.

Description

The QSC AD-S282HT Surface Mount Loudspeaker incorporates the Advanced Directivity rotatable waveguide. Available in black or white, these weather resistant enclosures can be painted to match any specific decor.

The AD-S282HT is a 2-way system housed in a ported enclosure made from injection molded, high-impact polystyrene. This enclosure incorporates two 8" weather-resistant, LF transducers with heavy-duty double roll cloth surrounds. These high output versions employ a 1" exit compression HF driver. The HF driver is coupled with QSC's unique Advanced Directivity rotatable waveguide - enabling the loudspeaker to deliver accurately focused sound, regardless of its mounted orientation.

Features

Contemporary Style, Weather Resistant Enclosure and Components - ideal for a wide range of applications.
Dual 8-Inch, 2-Way System - in a lightweight, multipurpose enclosure featuring a heavy duty, powder coated aluminum grill.
Versatile Mounting Options - The included yoke mount bracket can be used for mounting and aiming the system in vertical or horizontal orientations. Provision for optional Omni-mount bracket is built in.
Advanced Directivity Rotatable Waveguide - (90° x 60°) enables the loudspeaker to deliver accurately focused sound, regardless of the enclosure's mounted orientation.
Low Impedance and Transformer Versions - Standard 8 ohm system is selectable for passive or active operation while the AD-S282HT transformer version provides taps for both 70V and 100V distributed system use.

Specifications

Configuration	Compact two way, ported enclosure
Active or Passive	Passive
Frequency Response	80 Hz - 27.7 kHz
Power Capacity	450W RMS (8 hours IEC)
Nominal Sensitivity	93 dB
Nominal Impedance	8 ohms (5.25 ohms minimum, 17.6 kHz, 64.22 ohms maximum, 2.56 kHz)
Crossover	Not Specified by Manufacturer
Low Frequency Driver	8"
High Frequency Driver	1" Exit Compression HF Driver
Enclosure Material	Injection Molded Polystyrene with Aluminum Grille
Input Connections	Barrier Strip (switchable: passive/active on AD-S282H)
Taps	70V 200, 100, 50, 25 Watts; 100V 200, 100, 50 Watts
Dimensions	10.21" H x 26.17" W x 11.44" D (259 mm x 685 mm x 290 mm)
Net Weight	27.7 lbs (12.6 kg)
Shipping Weight	35.6 lbs (16.1 kg)
