The CX108V provides 100 watts per channel at 70 volts respectively. With both models, each pair of channels may be bridged to configure these amplifiers as 4, 5, 6 or 7 channel units. Like the entire CX Series, the 8-channel models feature DataPorts for remote amplifier management or signal processing, incorporate QSC's legendary PowerLight technology, and deliver our unmatched reputation for quality and reliability.
QSC's PowerLight technology takes your audio to an entirely new level. Delivering tighter bass and clean, transparent highs, PowerLight also cuts waste heat, boosts reliability, and eliminates unwanted noise and hum. PowerLight is a revolutionary switching power supply technology that provides ample current to the audio power circuitry by charging the supply rails 230,000 times per second through an ultra-low noise impedance circuit. Unlike amplifiers that use conventional supplies, the audio signal is never starved prematurely and remains crisp and clean.
| 70V (0.2% THD 20 Hz-20 kHz) | 100W |
|---|---|
| 140V (0.2% THD 20 Hz-20 kHz) | 200W |
| Noise (20 Hz - 20 kHz) | -100 dB |
| Input Sensitivity (for full-rated output power) | 1.26 Vrms @ 70V |
| Voltage Gain | 56x (35 dB) |
| Input Clipping | 6 Vrms (+18 dBu) |
| Output Circuitry | Class AB+B |
| Frequency Response | 20 Hz - 20 kHz, ± 0.4 dB8 Hz - 70 kHz, +0/-3 dB |
| Damping Factor | Greater than 500 (5 kHz and below) |
| Input Impedance | 6 kilohms unbalanced,12 k ohm balanced |
| Distortion (SMPTE-IM) | Less than 0.02% |
| Connectors | INP: 3 position Euro-style detachable terminal block, DataPort: HD-15 OUT: Two 8-position blocks |
| Cooling | Variable speed fan, rear-to-front airflow through tunnel heat sink |
| Amplifier Protection | Full short circuit, open circuit, thermal, ultrasonic, and RF protection |
| Load Protection | On/off muting; Individual channel DC fault blocking |
| Power Requirements | 100, 120, 230 VAC, 50-60 Hz |
| Dimensions (H x W x D) | 3.5" (88.9 mm) x 19" (482.6 mm) x 14" (355.6 mm) |
| Net Weight | 21 lbs (9.5 kg) |
| Shipping Weight | 27 lbs (12.3 kg) |
