QSC ISA1350 ISA Series Power Amplifier (Discontinued)

Name: QSC ISA1350 ISA Series Power Amplifier (Discontinued)
Brand: QSC Audio
SKU: QSC-ISA1350
Price: 1970 USD
Availability: OutOfStock

Write a Review

Part #:

ISA1350

Model #:

ISA1350

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The QSC ISA 1350 Amplifier includes a selectable high-pass filter to protect speakers and prevent speaker transformer saturation with minimal effect on program material. The ISA Series provides additional protection circuitry.

Description

The ISA1350 Amplifier includes a selectable high-pass filter to protect speakers and prevent speaker transformer saturation with minimal effect on program material. The ISA Series provides additional protection circuitry including DC, infrasonic, thermal overload, RF and short circuit protection. Versatile loading options and a comprehensive feature set make the ISA Series a rugged, cost-effective power solution for any permanently installed sound system.

Features

ISA 1350 drives 70V lines directly with 1500 watts / channel
Rear panel gain controls for tamper resistant operation with 2 dB detents for quick and repeatable settings
XLR and detachable Euro style input connectors
DataPort V2 for use with DPV2-compatible signal processing accessories (XC-3, SF-3, LF-3) and DSP-3/DSP-4 (with external power supply)
Independent defeatable clip limiters for reduced distortion
Front panel indicators include power, signal, and clip
Covered barrier strip output connectors for safety agency compliance
Automatic variable-speed fan for quiet normal operation with maximum cooling on demand
Rear-to-front air flow keeps equipment racks cool
Stereo, Bridge, or Parallel operating modes
Comprehensive protection circuitry including DC, infrasonic, thermal overload and short circuit protection
25, 70, 100 volt, and low-impedance outputs available simultaneously

Specifications

Stereo Mode Both Channels Driven
8 Ohms
20 Hz-20 kHz 0.1% THD	800W
4 Ohms
20 Hz-20 kHz 0.1% THD	1300W
2 Ohms
1 kHz 1% THD	2000W
Direct Power, Stereo Mode
70V	1500W
Bridged Mono Mode
8 Ohms
1 kHz 0.1% THD	2800W
4 Ohms
1 kHz 1% THD	4000W
XF Output Power, Bridged Mono Mode
Signal to Noise (20 Hz-20 kHz)	100 dB
Distortion (SMPTE-IM)	Less than 0.01%
Input Sensitivity @ 8 ohms	1.24v (+4.1 dBu)
Voltage Gain @ 8 ohms	64.0x (36.1 dB)
Output Circuitry	Class H, 3 Tier
Distortion (Typical)
20 Hz-20 kHz: 10 dB below rated power	Less than 0.03% THD, 4 ohms and 8 ohms
1.0 kHz and below: full rated power	Less than 0.03% THD, 4 ohms and 8 ohms
Frequency Response 10 dB below rated output power	20 Hz-20 kHz, +0/-1 dB; -3 dB points: 5 Hz and 50 kHz
Damping Factor (direct outputs)	Greater than 200 at 8 ohms, ISA 1350 greater than 250
Input Impedance	10 k ohms unbalanced, 20 k ohms balanced
Input Clipping	10 Vrms (+22 dBu)
Cooling	Continuously variable speed fan, back-to-front air flow
Amplifier Protection	Full short circuit, open circuit, thermal, ultrasonic, and RF protection
Power Requirements	120, 230, VAC, 50-60 Hz
Net Weight	68 lbs (30.8 kg)
Shipping Weight	77 lbs (34.4 kg)
Dimensions	5.25" H x 19" W x 15.9" D (133 mm x 483 mm x 404 mm)
