The Rolls MA1705 5-input 70V mixer amplifier is a single rack space mixer amplifier designed for installation applications. This unit provides a compact and efficient way to mix up to three sources such as AM/FM tuners, CD players and video players with up to two microphones.

Description

Rolls MA1705 5-Input 70 Volt Single Rack Space Mixer Amplifier

The Rolls MA1705 5-input 70-volt mixer amplifier 70-watt is a single rack space mixer amplifier designed for installation applications. The unit provides a compact and efficient way to mix up to three sources such as AM/FM tuners, CD players and video players with up to two microphones. Priority talkover is provided on Microphone One for paging and on Source Three for a jukebox, telephone, etc. The power amplifier provides 70 Watts of power when connected to a 70 volt speaker system.

Features

Two Microphone inputs with phantom power
Tone controls for each Mic input
Three stereo Source inputs (mixed to mono)
Bass and Treble controls on Sources Tow and Three
Priority ducking on Mic Two and Source One
Dual pre-master level Record Output
Fault protected power amp
Balanced 70 volt line output
Spring-loaded output terminals
Clip indication
FR4 Double-sided epoxy circuit board
Socketed ICs

Specifications

Mixer Input Impedance
Mic	600 Ohms XLR balanced
Source	22K Ohms RCA
Insert	22K Ohms 1/4" TS unbalanced
Max Input Level
Mic	-14 dBV Mic level Max
Source	24 dBV
Insert	+20 dB
Connectors	2: XLR, 6: Stereo RCA, 3: 1/4" TRS, 1: 1/4" TS
Phantom Power	+12 VDC
Max Gain
Mic	60 dB
Source	26 dB
Tone Controls	+/-12 dB 100 Hz Bass+/-12 dB 11kHz Treble
Noise Floor	- 80 dB
S/N Ratio	96 dB
Priority Attenuation	60 dB
Power Amplifier
Recommended Load	70 Volt line (70 Watts maximum)
Frequency Response	60Hz to 20 kHz
Dimensions (H x W x D)	1.75" (44.5 mm) x 19" (482.6 mm) x 5" (127 mm)
Weight	5.5 lbs (2.5 kg)
